Maxwell Digital Multimeters 25328 Anwendungsinformation Seite 6

EN
User Manual
Measuring specifications - precision
The below precise values (taken from various
thresholds) which the device guarantees
for 1 or 2 years under proper use, 18ºC-28ºC
temperatures and 75% relative humidity.
Precision display: ± (% value numbers + number
of lower values).
DC voltage
Threshold Resolution
600mV 0,1mV
6V 1mV
60V 10mV
600V 100mV
1000V 1V
AC feszültség
Threshold Resolution
600mV 0,1mV
6V 1mV
60V 10mV
600V 100mV
700V 1V
Frequency range
Overload protection
Inward impedance
Frequency (10 Hz - 1 MHz)
Threshold Resolution
99,99 Hz 0,01 Hz
999,9 Hz 0,1 Hz
9,999 kHz 0,001 kHz
99,99 kHz 0,01 kHz
999,9 kHz 0,1 kHz
Precision
±(0,5% + 8)
±(0,8% + 5)
±(1,0% + 10)
Precision
±(3,0% + 3)
manual mode
only
±(1,0% + 3)
±(1,5% + 3)
40Hz-400Hz,
1000V DC or 700V AC
rms.
DC and AC voltage
>10MΩ
Precision
±(0,1% + 3)
Resistance
Threshold Resolution
600Ω 0,1Ω
6kΩ 1Ω
60kΩ 10Ω
600kΩ 100Ω
6MΩ 1kΩ
60MΩ 10kΩ
Overload protection 250V DC or AC rms
Diode or continuity test
Measuring
Opening voltage
Measuring Threshold
Precision
Opening DC current
Closing DC voltage
Continuity beep
Overload protection
Temperature
Threshold Resolution
-55 ºC - 0ºC
1 ºC - 400 ºC
401 ºC - 1000 ºC
Overload protection
Capacity
Threshold Resolution
60nF 10pF
Precision
±(0,5% + 3)
±(0,5% + 2)
±(1,5% + 3)
Threshold Resolution
600Ω 0,1Ω
kb. 0,5 V
Resolution
1V 0,001V
1% negligible
1mA
1,5V
below <50Ω
250V DC or AC rms
Precision
±(5,0% + 4ºC)
0,1ºC
±(2,0% + 3ºC)
1ºC ±2,0%
250V DC or AC rms
Precision
±(3,0% +20)
