DUTY button again.
Read the value on the screen in %
Set the function button to Hz threshold.
Connect the black wire to the „COM"
connector, and the red to the „Hz" connector.
Connect the device to the circuit and read the
frequency value from the display.
Note: When measuring low signals it is advised to use shielded
cables for precise values.
Temperature measuring
Set the function button to ºC position!
Connect the type K probe to the device, the
red connector to the ºC connector, and the
black to the „COM" connector.
Make the probe touch the subject or place it in
the measured environment.
Read the temperature value from the screen.
WARNING: To avoid electric shock the probe should not be
placed into electric environment or used in a microwave$
Current measuring
Measurement thresholds: 600µA, 6000µA,
60mA, 600mA, 6A, 10A.
Turn off the power source for the measured
circuit. Discharge all high-capacity capacitors.
Set the function button to µA, mA or A mode.
Press the „SELECT" button to select the DCA or
ACA measuring mode.
Connect the black wire to the „COM" connector
and the red to the mA terminal for 600mA
maximal threshold, or to A for 10A maximal
threshold.
Connect the device to the circuit (serial)
Read the displayed value from the screen.
When measuring DC, the polarity of the red
cable is also displayed (negative only)
If „OL" is displayed and the device is constantly
beeping, switch to a higher measuring
threshold.
WARNING: To avoid damage to the device always check
the state of the fuse before measuring! Always use the
specified connectors!
PC Link
The device has a data connector, which enables
it to connect to a computer's serial port. Thus
the measured data is available for processing
(save, analyze, print, etc.) on the computer.
Before connecting the supplied PC-Link soft-
ware needs to be installed on the computer.
Press and hold the Hz/DUTY button and turn
on the device, this gets you into PC-Link mode.
The PC-LINK icon will be lit on the screen,
and the serial data transmission mode will be
active.
t
ecHnical paraMeters
Name
Environmental
parameters
Pollution
coefficient
Height coefficient <2000 m
Operating
temperatures
Storage
temperatures
Temperature
coefficient
Maximum voltage
between the
connector and the
ground
Fuse
Sampling 3x/sec
Display
Threshold
selection
Overrange
indication
Low battery
indication
Polarity indication
Power 9V DC battery 6F22
Size 180 x 85 x 40 mm
Weight 310g (with battery)
EN
User Manual
Value
600V CAT III. and
1000V CAT II.
2
0ºC - 40ºC (<80%
humidity)
-10ºC - 60ºC (<70%
humidity)
0,1 x (determined
precision)/ ºC (<18ºC
vagy >28ºC)
700V AC rms or 1000V
DC
µA and mA - F
500mA/250V Ø5x20
and F 10A/600V Ø6x30
4 digit, automatic
indicator and symbol
display
automatic and manual
„OL" on the screen
" on the screen
„ - „ displayed on the
screen automatically
