General
POOL 20 is an accessory that enables pool heating with
VVM 240 and VVM 300.
POOL 20 contains the following components
1 x Actuator Shuttle valve
1 x Shuttle valve, Ø 22 mm
1 x Panel with terminal block
2 x Tie straps
1 x Heating pipe paste
1 x Aluminium tape
1 x Insulation tape
1 x Temperature sensor with round sleeves
For VVM 240 the CPU card version must be 1.11 or newer
otherwise it must be replaced.
(Part no. 618848)
Function
When the pool temperature has dropped below the set
start temperature (menu 8.4.3) and there is no hot water
demand, VVM 240/300 automatically switches between
pool charging and heating charging as long as the demand
remains.
During pool heating, the shuttle valve (19) changes direc­
tion and opens towards pool heat exchanger.
The proportion of pool charging in relation to heat charg­
ing is set in menu 8.5.1 and 8.5.2, where pool charging
takes over hot water charging time when there is no hot
water charging demand.
The heat medium flow is adjusted so that the temperature
difference over the pool heat exchanger (14) is 10­15 °C.
An external pool circulation pump can be connected but
the pool sensor must be installed in the submerged tube to
achieve the correct temperature even when the circulation
pump is not running. The pump starts at the same time as
the shuttle valve switches to pool and stops when the shut­
tle valve switches back.
The shuttle valve that switches between pool and heating
is controlled by relay 3 on the relay card.
If the pool sensor is not connected, the pool heating func­
tion deactivates. Only applies to VVM 300.
INSTALLATION INSTRUCTIONS
POOL 20

Program settings

Menu 8.1.1 Menu type
■
Select "Service" to gain access to all the menus.
Menu 8.4.1 Pool control
■
Activate pool control by selecting "On".
The factory setting is "Off".
Menu 8.4.2 Pool temperature
■
Current temperature at pool sensor appears.
Menu 8.4.3 Pool start temp
■
Here you select the temperature at the pool sensor (3)
that heating of the pool is to be permitted. The value
can be set between 5 and 40 °C. The factory setting
is 25 °C.
Menu 8.4.4 Pool stop temp
■
Here you select the temperature at the pool sensor (3)
that heating of the pool is to be stopped. The value
can be set between 5 and 40 °C. The factory setting
is 28 °C.
Menu 8.5.1 Period time
■
Here you select the length of the period. The value is
adjustable between 5 and 60 minutes.
The factory setting is 60 minutes.
Menu 8.5.2 Max time for HW
■
Here you select how much time of the period time
(Menu 8.5.1) is to be used to heat the hot water, or
pool if there is no heat demand. The value is adjust­
able between 0 and 60 minutes.
The factory setting is 30 minutes.
Note!
POOL 20
Electrical installation and serv-
ice must be carried out under the
supervision of a qualified electri-
cian.
Electrical installation and wiring
must be carried out in accordance
with the stipulations in force.
