Description of the display icons

See illustration B on the folded cover page.
14. CTCSS code
15. Channel number
16. RX icon
– Displayed when receiving a signal
17. Speaker volume indicator
18. Call icon
– Displayed when you are sending out a call tone
19. VOX icon
– Displayed in Voice controlled (Vox) mode
20. Lock icon
– Displayed when the key pad is locked.
21. Scan icon
– Displayed when scan mode is active
22. Dual Scan icon
– Displayed when dual scan mode is active
23. Battery charge level indicator
24. Time
25. TX icon
– Displayed when transmitting a signal
8

Installation: Belt clip, lanyard and batteries

A
B
28
8.1 Removing/Installing the Belt Clip and
lanyard
• To remove the clip from the unit, push the belt
clip (B) towards the antenna, while pulling the clip
tab (A).
C
• When re-installing the belt clip, a click indicates
the Belt Clip is locked into position.
• On the Lanyard connection
an armband or neck strap.
8.2

Battery Installation

• Remove the belt clip (see chapter 8.1).
• Loosen the screw in a counter clockwise
direction using a coin & open the battery
compartment. (C)
• Install the enclosed rechargeable batteries (AAA)
following the polarity as shown.
• Re-install the Battery Cover and Belt Clip (see
chapter 8.1).
