Technical Specifications

4.1 General Data

Counterbalance:
Balance plate:
Grades of drag:
Tilt angle:
Pan range:
Temperature range:
Weight:
Maximum load:
Camera fitting:
tripod / pedestal fitting:
Pan arms:
Batteries:
24 steps + Boost Button
120 mm/4.7" sliding range
horizontal and vertical 9 each and 0
+90 ° / -60°
360°
-40 ° C to 60 ° C/-40° to 140°F
13.7 kg/30.2 lbs
11.9 - 69.6 kg/26.3 - 153.5 lbs @ 200 mm cog
14.4-84.1 kg/31.8-185.4 lbs @ 150 mm cog
Touch & Go with camera plate 35
150 mm bowl with integrated flatbase-
fitting
Two telescopic pan bars with attach-
ment diameter: 28.5 mm / 1.1" (front),
35 mm / 1.4" (back) and 40 mm / 1.6"
at pan bar end. Adjustable length of
540 - 720 mm / 21.3" - 28.3"
3 each 625 U or LR9
