2.4 Basic safety information

Danger of explosion
` Do not use the magnetic sensor in explosive zones.
Movable parts
Bruising, rubbing, abrasing, seizing of extremities or clothes by touching
during operation any movable parts as for example sensor.
` Prevent people from access by installing protective facilities.
External magnetic fields
Failures and data loss occur if strong magnetic fields influence the internal
measuring system.
` Protect the magnetic sensor from impact by external magnets.
3 Identification
Please check the particular type of unit and type number from the identifi-
cation plate. Type number and the corresponding version are indicated in
the delivery documentation.
e. g. -
MSAC506 0023

4 Installation

4.1 Mechanical mounting

Magnetic sensor failure
` When mounting pay attention to the IP type of protection (see chap-
ter 8).
` Avoid impact on the device.
` Do not open the sensor yourself.
` Cable must be provided with strain relief. If necessary use drag chain
or protective sleeve.
Loss of measured values
` The tolerance and gap measures be observed over the whole measur-
ing length.
