ENGLISH
OPERATION MANUAL
FEATURES
• Professional multi-band sound enhancer: adds harmonics to the sound which
increases definition, presence and transparency.
• Improves bass punch considerably
• Separate variable subwoofer output with adjustable cutoff frequency
• Subwoofer inverter switch
• 50Hz/100Hz low cut filter
• Variable sound processing for perfect sound balance
• Enhancer multi-band tuning from 1kHz to 8kHz.
• Balanced XLR inputs/outputs

BEFORE USE

Check the contents:
Check that the carton contains the following items:
• SE 100 Enhancer unit
• Operating instructions
• Power cord with IEC-plug
JB SYSTEMS®
OPERATION MANUAL
1/29 SE 100
ENGLISH
SAFETY INSTRUCTIONS:
CAUTION
The lightning flash with arrowhead symbol within the equilateral triangle
is intended to alert the use or the presence of un-insulated "dangerous
voltage" within the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert
the user to the presence of important operation and maintenance
(servicing) instructions in the literature accompanying this appliance.
To prevent fire or shock hazard, do not expose this appliance to rain or moisture. Do
not place metal objects or spill liquid inside the unit. Electric shock or malfunction
may result.
INSTALLATION GUIDELINES:
• Install the unit in a well-ventilated location where it will not be exposed to high
temperatures or humidity.
• Placing and using the unit for long periods near heat-generating sources such as
amplifiers, spotlights, etc. will affect its performance and may even damage the
unit.
• The unit can be mounted in 19-inch racks. Attach the unit using the 4 screw holes
on the front panel. Be sure to use screws of the appropriate size. (screws not
provided)
Take care to minimize shocks and vibrations during transport.
• When installed in a booth or flight case, please make sure to have good ventilation
to improve heat evacuation of the unit.
• To avoid condensation to be formed inside, allow the unit to adapt to the
surrounding temperatures when bringing it into a warm room after transport.
Condense sometimes prevents the unit from working at full performance.
CONNECTIONS
This sound enhancer can be used in different ways. Basically the unit is connected
between the music source (any line output is possible) and the unit that will be used
to record or amplify the music:
• In most cases SE100 will be used to enhance the sound quality and bass punch in
PA systems and discotheque sound systems. The SE100 will be connected behind
the master output of the audio mixer. You can also use the subwoofer output to
drive an extra subwoofer amplifier which results in an additional power punch!
• SE100 can be inserted in the monitor send of a PA mixer to enhance the sound
quality of monitor speakers.
• SE100 can also be used between a tape deck and mixing console to enhance the
sound of the tape deck.
• SE100 can be connected between the record output of a mixing console and a tape
deck to enhance the sound that will be recorded.
• SE100 can be used to correct the loss of sound quality, caused by all kinds of effect
equipment. In this case put the SE100 as last unit in the chain of effect equipment.
JB SYSTEMS®
OPERATION MANUAL
CAUTION: To reduce the risk of electric
shock, do not remove any cover. No user-
serviceable parts inside. Refer servicing to
qualified service personnel only.
2/29 SE 100
