Siko AP03/1 Benutzerinformation Seite 8

: Change-over to relative value
display and simultaneous zero-setting
: Change-over to display of absolute
value
Only possible, if key
accordingly before!
Stepping mode
If key and either key
simultaneously, the correspondingly assigned swit-
ched output actuator 1 or 2 is activated. Switched
output actuator 3 remains passive, ie. stepping
mode is only possible during creep traverse.
and : stepping mode actuator 1 (I)
and : stepping mode actuator 2 (E)
Only possible, if key
accordingly before!
Setting of the device address
Switch unit on. Press key
until menu point "Adr" appears. Press key
the desired address is displayed. Press key
store the address. After address modification, AP03/
1 must be switched on and off again to make the
modification become effective.
8 AP03/1
has been programmed
or are pressed
has been programmed
for at least 15 seconds
until
to
Datum 13.02.2003 Art.Nr. 78439
6. Calibration
Calibration is made electronically as follows and
irrespecitive of mounting:
• Approach a mechanically defined position (eg.
end of travel or machine's zero position ...).
• Unless AP03/1 has already been pre-programmed
at the factory, then enter the value (calibration
value) which corresponds to this position (see
chapter 7).
• Use a SW 2 hex key to unscrew the frontal
calibration screw up to its limit; then retighten the
screw (this is activating an internal switch which in
turn triggers calibration - fig. 1).
Important information: The available regulation
range is achieved symmetrically in both directions
of rotation. Example: AP 03/1 with 12 bit (4096)
turns, - for both directions 11 bit (2048) turns are
available
7. Programming
Please inquire!
8. Service operation -
list of commands
Please inquire!
SIKO GmbH
Dr.-Ing. G. Wandres
Werk / Factory:
Weihermattenweg 2
D-79256 Buchenbach
Postanschrift / Postal address:
Postfach 1106
D-79195 Kirchzarten
Telefon / Phone 0 76 61 / 3 94 - 0
Telefax / Fax 0 76 61 / 3 94 - 388
eMail info@siko.de
Internet www.siko.de
Z.Nr. 8665015 Änd.Stand 63/03
