AVENTICS | AV03/AV05 | R412018507–BAL–001–AI | English
1 End plate with D-Sub connection
2 Exhaust module with surface silencer
3 Valve
4 Blanking plate
5 End plate, right
6 Base plate, 2x
7 Base plate, 3x
8 Supply plate
The components in detail
Overview of bus coupler connection, I/O module, module with auxiliary
3
power supply
A Bus coupler
B I/O module
C I/O module with auxiliary power supply
D I/O module, M12 digital inputs/outputs
E I/O module with spring clamp connection
f IO-Link
1 Fieldbus connection X7xx
(xx = depending on fieldbus)
2 Fieldbus connection X7xx
(xx = depending on fieldbus)
3 M12 connection for X1S power
supply
Overview of supply plates and exhaust modules
Supply plates make it possible to vary the channeling, separation, or supply of
compressed air in the valve system. Supply plates can be used, for example, as
separation and supply plates when operating with multiple pressure zones. With a
corresponding exhaust module, the exhaust air can be evacuated via a surface
silencer or the tubing connections 3 and 5.
A Supply plate for pressure supply to channel 1, internal pilot air
B Supply plate for pressure supply to channel 1, external pilot control
C Exhaust module with surface silencer for 3/5 and R
D Exhaust module with restricted exhaust 3/5
E Exhaust module with separate restricted exhaust for 3 and 5
f Supply plate for auxiliary pressure supply to channel 1, separate pressure zones
in channels 1, 3, and 5
G Supply plate for auxiliary pressure supply to channel 1, separate pressure zones
in channels 3, and 5
H Supply plate for auxiliary pressure supply to channel 1, separate pressure zone
in channel 1
I Supply plate for auxiliary pressure supply to channel 1, no pressure zones
J Supply plate for auxiliary pressure supply to channel 1, external pilot control
connection X
K Electrical supply plate with electrical connection
L Electrical supply plate with external pneumatic pilot control and electrical
connection
m Electrical valve control module with electrical connection
N Supply plate AV-BP for auxiliary pressure supply and to separate pressure
zones
1 Hole for exhaust module mounting
screw
2 Channel 1: compressed air
connection
3 Channel X: external pilot control
4 Electrical contact feedthrough
5 Hole for tie rod mounting
9 Exhaust module for restricted
exhaust
10 Retaining brackets
11 Left end plate for bus coupler and I/O
modules
12 Bus coupler
13 Transition plate
14 I/O module unit
15 Right end plate, stand-alone
16 Left supply plate, AV-BP
17 Central supply plate, AV-BP
4 Ground (functional earth)
5 Electrical connection for AES modules
6 Auxiliary power supply connection
7 Functional earth (optionally available)
8 X7I1, IO-Link connection
4
6 Mounting screw
7 Exhaust air port on exhaust module
8 Electrical connection
9 FE connection
10 Channel 1, 3, 5: compressed air
connection to AV-BP supply plate
11 Mounting point for valve system/
transition plate
Base plates, 2x, base plates, 3x
Base plates have two or three slots for valves or functional elements. Only double
base plates are available for the AV-BP series.
5
Overview of base plates
1 Base plate, 3x
2 Base plate, 2x
3 Connection openings for push-in
fittings 2 and 4 for operating lines
4 Holes for tie rods
Base plate marking
Base plates are available in two versions:
For single solenoid valves:
Only single solenoid valves can be operated.
If a double solenoid valve is mounted, only solenoid 14 can be used.
For double solenoid valves:
Single and double solenoid valves can be operated.
Base plates for single solenoid valves have a marking on the back side.
Base plates for double solenoid valves do not have any marking.
Valves
The valves direct the air to the pneumatic drives. The connection is made via the
valve's base plate.
2x 3/2 directional valves (2 independent valves in one housing)
5/2 and 5/3-directional valves
Overview of directional valve (A) and blanking plate (B)
1 Manual override:
– Yellow control button: press and turn
– Red control button: press without detent
2 LED (yellow): An illuminated LED indicates that the assigned solenoid coil is
energized.
In valves with two solenoids, the solenoids are correspondingly labeled "12" and
"14".
3 Mounting screw: oval-head screw M2.5, Torx T8 acc. to ISO 10664
Overview of AV-EP pressure regulator
1 AV-EP pressure regulators for
multipole connection with display
2 AV-EP pressure regulators for
multipole connection without
display
8
Right end plates
1 Right end plate without port for
restricted pilot exhaust air
2 Right end plate with port for
restricted pilot exhaust air
5 Assembly
Danger of injury if assembled under pressure or voltage!
Assembling when under pressure or electrical voltage can lead to injuries and
damage to the product or system components.
Make sure that the relevant system part is not under voltage or pressure
before you assemble the product.
Protect the system against being restarted.
Damage to the valve system due to improper handling
When removing the valve system from its packaging, the valve system can be
damaged due to bending, especially with long devices.
Carefully remove the valve system packaging and provide safeguards against
torsion and bending.
Mounting options
The following options exist for mounting the valve system, see figures
5 Circuit board feedthrough
6 AV-EP base plate, single pressure control
7 AV-EP base plate, pressure zone control
8 Thread connection 2 and 4 for operating
line
9 Label area
6
7
3 AV-EP pressure regulators for fieldbus
connection with display
4 AV-EP pressure regulators for fieldbus
connection without display
3 Right end plate and bus coupler,
stand-alone
4 Right end plate with port for
restricted pilot exhaust air
5 Right end plate fir flexible pilot
exhaust air with connection for
restricted pilot exhaust air
CAUTION
NOTICE
9
9a and 9b .
