9.3 Washer kit, tank of 23l (6gal),
pump with 11m (36ft) delivery
head

9.3.1 Mechanical

Polyethylene tank, stainless steel cage
Dimensions (WxHxL): 301x410x348mm
(11.8x16.1x13.7in)
Unit weight: 5.9kg (13lb)
Water tank capacity: 23l (6gal)
Delivery head: 11m (36ft) max
Tube length: 11m (36ft)
9.3.2 Electrical
Supply voltage/Current consumption:
• 230Vac, 0.5A, 50/60Hz
• 120Vac, 1A, 50/60Hz
• 24Vac, 3.8A, 50/60Hz
9.3.3 Environment
Operating temperature
• Maximum temperature: 60°C (140°F)
• Minimum temperature with antifreeze liquid in
solution : -10°C (14°F)
• Minimum temperature with antifreeze liquid
in solution (reduced performance and delivery
height): -25°C (-13°F)
9.3.4 Certifications
Electrical safety (CE): EN60950-1
Electromagnetic compatibility (CE): EN50130-4,
EN61000-6-3, EN55032, (Class B), FCC Part 15 (Class B)
Outdoor installation (CE): EN60950-22
IP protection degree (EN60529):
• IP66
EAC certification
MNVCWAS_1744_EN
9.4 Washer kit, tank of 23l (6gal),
pump with 30m (98ft) delivery
head
9.4.1 Mechanical
Polyethylene tank, stainless steel cage
Dimensions (WxHxL): 301x620x348mm
(11.9x24.4x13.7in)
Unit weight: 13.9kg (30.6lb)
Water tank capacity: 23l (6gal)
Delivery head: 30m (98ft) max
Tube length: 30m (98ft)
Switch for liquid level
9.4.2 Electrical
Supply voltage/Current consumption:
• 230Vac, 2A, 50/60Hz
• 120Vac, 4.5A, 60Hz
9.4.3 Environment
Operating temperature
• Maximum temperature: 60°C (140°F)
• Minimum temperature with antifreeze liquid in
solution: -10°C (14°F)
9.4.4 Certifications
Electrical safety (CE): EN60950-1
Electromagnetic compatibility (CE): EN50130-4,
EN61000-6-3, EN55032, (Class B), FCC Part 15 (Class B)
IP protection degree (EN60529):
• IPX4
EAC certification
