WASPT 5 or 23 liter tank with pump English - Instructions manual Italiano - Manuale di istruzioni Français - Manuel d’instructions Deutsch - Bedienungslanleitung Русский - Руководство по эксплуатации...
WASPT 5 or 23 liter tank with pump 1 About this manual 3 Safety rules Before installing and using this unit, please read this CAUTION! The electrical system to which manual carefully. Be sure to keep it handy for later the unit is connected must be equipped reference.
5 Preparing the product for • Use only original spare parts. Non-original spare parts could cause fire, electrical discharge or other hazards. • Before proceeding with installation, check the Any change that is not expressly approved supplied material to make sure it corresponds by the manufacturer will invalidate the to the order specification by examining the guarantee.
6 Installation 6.1 Installing the pump tank We recommend filling the tank with water at room temperature. If using the pump at temperatures below 3°C (37.4°F) add some glass cleaner antifreeze liquid to the water. The antifreeze liquid will cause irreparable damage to the germanium windows.
6.2 Choosing the power supply 6.4 Board description Depending on the version, the device can be BOARD DESCRIPTION provided with different power supply voltages. Their Connector Function value is shown on the product identification label. Board power supply Electrical connections must be performed Wiper with the power supply disconnected and Optional board (DTWRX)
6.5 Connection of the board 6.5.2 Pump and alarms connection All the connections of terminal J9 must Find, on the pump control board, the position of the have very low safety voltage. fuses (FUS1, FUS2, FUS3), the power supply terminal (J1), the wiper connector (J7), the control terminal Connect the Pan &...
6.5.3 Wiper connection REMOTE CONTROL WITH DTWRX OPTIONAL BOARD Connector Function Notes If you are using a pan & tilt equipped with RS-485-A Connector RS-485 Connect to the a wiper, skip the instructions here below A (+) RS-485-A serial and follow those provided in the relative line coming from manual.
6.6 Pump installation 6.6.3 Pump with 30m (98ft) delivery Avoid contact with the pump motor. Be very careful not to start the pump when Surfaces are hot and may cause personal the tank is empty. injury if touched. If present, the float switch allows to Adjust the position of the level controller and the automatically stop the pump.
Seite 10
6.7 Washer installation (ULISSE) Lock the nut to the coupling. To attach the base to the support use the provided screws (05), washers (06), screw gaskets (07) and gasket (08). Fastening the support (01), place the washer pipe Fig. 15 support (03) in the desired position.
6.7 Washer installation (ULISSE 6.7.1 Installation examples COMPACT) Position the nozzle support bracket (01) in the appropriate groove on the base (02) and lock it using the 2 screws (03). Remove the nozzle (04) from the supplied pipe. Position the nozzle and lock it using washer and nut (05).
7 Maintaining 8 Disposal of waste materials 7.1 Fuses replacement 7.1.1 Replacing the fuse of the pump This symbol mark and recycle system are applied only to EU countries and not board applied to the countries in the other area of The used fuse is described below.
9 Technical data 9.2 Washer pump, tank of 23l, 5m (16ft) delivery The product has been designed to work intermittently. 9.2.1 Mechanical 1 minute: ON. 15 minutes: OFF. Polyethylene tank, stainless steel cage 9.1 Washer pump, tank of 5l, 5m Dimensions (WxHxL): 301x410x348mm (11.8x16.1x13.7in) (16ft) delivery...
Seite 14
9.3 Washer pump, tank of 23l, 9.4 Washer pump, tank of 23l, 11m (36ft) delivery 30m (98ft) delivery 9.3.1 Mechanical 9.4.1 Mechanical Polyethylene tank, stainless steel cage Polyethylene tank, stainless steel cage Dimensions (WxHxL): 301x410x348mm Dimensions (WxHxL): 301x620x348mm (11.8x16.1x13.7in) (11.9x24.4x13.7in) Unit weight: 6.7kg (14.8lb) Unit weight: 15.1kg (33.3lb) Water tank capacity: 23l (6gal)
10 Technical drawings The dimensions of the drawings are in millimetres. Fig. 23 Water tank 5l (1.3gal), 5m (16ft) delivery. Fig. 24 Water tank 23l (6gal), 5m (16ft) delivery. MNVKWASPT_1511_EN...
Seite 16
Water tank 23l (6gal), 11m (36ft) delivery. Fig. 26 Water tank 23l (6gal), 30m (98ft) delivery. Headquarters Italy Videotec S.p.A. Via Friuli, 6 - I-36015 Schio (VI) - Italy Tel. +39 0445 697411 - Fax +39 0445 697414 Email: info@videotec.com www.videotec.com...
