Thank you for purchasing this Stuart
product. To get the best performance from
the equipment, and for your personal
safety, please read these instructions
carefully before use.
Stuart hotplates and stirrers are designed to
operate under the following conditions:-
❖ For indoor use only
❖ Use in a well ventilated area
❖ Ambient temperature range +5°C to +40°C
❖ Altitude to 2000m
❖ Relative humidity not exceeding 80%
❖ Mains supply fluctuations not exceeding 10%
of nominal
❖ Overvoltage category II IEC60364-4-443
❖ Pollution degree 2 IEC664
❖ Use with a minimum distance all round of
200mm from walls or other items
If the equipment is not used in the manner
described in this manual the protection provided
by the equipment may be impaired.

Electrical Installation

THIS EQUIPMENT MUST BE EARTHED
Before connection please ensure that the
line supply corresponds to that stated on
the rating label.
Power requirements:
Model
CD162 230V, 50/60Hz,~
SD160 230V, 50/60Hz,~
SD162 230V, 50/60Hz,~
CD162/LV 100-120V, 50/60Hz,~ 550W
SD160/LV 100-120V, 50/60Hz,~ 700W
SD162/LV 100-120V, 50/60Hz,~ 750W
There is an IEC socket at the rear of the
instrument for connection to the mains supply,
(see figure 2). The unit is supplied with two
mains leads fitted with IEC plugs for connection
to the instrument. One has a U.K. 3 pin plug
and the other has a 2 pin "Schuko" plug for
connection to the mains. Choose the lead
appropriate for your electrical installation and
discard the other.
Should neither lead be suitable, take the lead
with the U.K. plug and replace the plug with a
suitable alternative. See the enclosed instruction
sheet for advice on how to carry out this
procedure.
Should the mains lead require replacement a
cable of 1mm
connected to an IEC 320 plug should be used.
The mains lead should be connected to the
instrument BEFORE connection to the mains
supply.

Operation

Use as a Hotplate
CD162, SD160 and SD162
Ensure that the external temperature probe is
NOT connected to the instrument.
The control knob on the left hand side of the
display controls the heating function.
To switch on the heating function briefly press
and release the knob. Repeat to turn off the
heating function.
When switched on the display will show actual
plate temperature at the bottom of the screen
and the set temperature directly above. The
heating icon will show , indicating that the
displayed temperatures are those of the plate
surface.
The plate temperature can be selected and
controlled to a resolution of 1°C.
550W
To increase the set temperature turn the knob
700W
clockwise until the required setting is shown in
750W
the display. To decrease the setting turn the
knob anti-clockwise.
The unit will now begin to heat until the set
temperature is reached and then will hold the
plate at this value. The actual plate temperature
is continuously displayed at the bottom of the
screen. When the set temperature is reached an
alarm will sound. When the plate surface is too
hot to touch (> 50°C) a red warning light on the
front panel will begin to flash. This will continue
to flash while the plate temperature is above
50°C even after the heating function is turned
off.
2
of harmonised code H05W-F
IF IN DOUBT CONSULT A QUALIFIED
ELECTRICIAN
WARNING: The top surface of the
instrument may be HOT. In free air a
1
