2.1. DC VOLTAGE

Ranges :

50 - 150 mV

0.5 - 1.5 - 5 - 15 - 50 - 150 - 500 V

FSD current : 25 µ A

1500V (on separate input)

Accuracy at FSD : ± 1 . 5 % (± 3 % on 1500 V range)

S e n s i t i v i t y : 4 0 kW / V ( 1 0 kW / V on 1500 V range)

Extensions : 15 and 30 kV (see EHT probes)

2.2. AC VOLTAGE

Ranges :

5 - 15 - 50 - 150 - 500 V

FSD current : 250 µ A

1500V (on separate input)

Accuracy at FSD : ± 2.5 % (± 4 % on 1500 V range) ref. 45 - 65 Hz

S e n s i t i v i t y : 4 kW / V

Frequency response : see table page 19

Decibelmeter :

- 10 to + 56 dB

Direct scale 0 to + 16 dB

2.3. DC CURRENT

Ranges :

2 5 µ A (on 50 mV and any other V DC range with FSD current 25 µ A )

150 µ A - 1.5 - 15 - 150 mA

1.5 - 15 A (on separate inputs)

Accuracy at FSD : ± 1.5 %

Voltage drop : < 1.2 V

Extension shunts : 100 and 300 mV 15 A up to 500 A

2 - SPECIFICATIONS

0 dB = 1 mW / 600 W

MX 430B
