Sideguard

The sideguards of the SIMBA are primarily designed for the new
integrated sideguard brakes. If you have not ordered the integrated
sideguard brakes then the openings in the sideguard are fitted with
covers, (Fig.5.20).
WARNING!
If the sideguard is used without the covers, then this presents a risk
of injury. Where the integrated sideguard brake is not fitted, then
there must be a cover.
Armrest
The armrest is screwed into place on the sideguard at the designated
position. The armrest is height-adjustable.
Therapy table
A therapy table can only be used in combination with the armrest. It is
fixed onto the armrest and is positioned on both armrests

Push handles

DANGER!
A wheelchair should never be lifted with an occupant; it should only
be pushed.
Height-adjustable push handles
These handles are secured with pins to prevent them from sliding out
unintentionally. Opening the quick-release lever (1) makes it possible
to adjust the height of the push handles (2) to meet your individual
needs. As you move the lever, you will hear a locking mechanism;
you may now easily position the push handle as desired.
The nut on the tension lever determines how tightly the push handles
are clamped into place. If the nut is loose after adjusting the tension
lever, the push handle will also be too loose. Turn the push handle
from side to side before use to make sure that it is clamped securely
enough into place.
After adjusting handle height, always clamp the tension lever (1)
securely into place. If the lever is not secure, injuries could result
when ascending stairs (Fig. 5.21 + 5.21.1).
CAUTION!
If the height-adjustable push handles are not fitted properly, there is
a risk that these will develop "play" or that they move out of position.
Please make sure that the relevant screws are tightened correctly.
Fold-down push Handles/Bar
If the push handles are not in use, they can be folded down by
loosening the levers, (2). When they are needed again, simply
flip them back up until they click into place and tighten the levers,
(Fig.5.22).
Simba
Fig. 5.20
Fig. 5.21
Fig. 5.21.1
1
Fig. 5.22
2
21
2
