Extra features:
Long lasting battery life
"Picture-in-Picture" mode
Color palettes
Observation modes
Calibration modes (non-uniformity correction)
Manual contrast and brightness adjustment
4
EXTERNAL VIEW AND CONTROLS
Power ON/OFF button
1
Navigation button UP
2
Button MENU
3
Recording button REC
4
Navigation button DOWN
5
Interpupillary distance adjustment rings
6
Dioptre adjustment rings
7
Lens focusing ring
8
Battery Pack
9
Battery Pack latch
10
Tripod mount
11
Radiator cooling system
12
Lens cover
13
Objective lens
14
MicroUSB port
15
MicroUSB cable
16
Please refer to the picture (Pic.1) on the front flyleaf.
3
5
FUNCTIONS OF CONTROL BUTTONS
BUTTON CURRENT FIRST SHORT
OPERATING MODE PRESS
Device is off Power device on Calibrate the sensor
ON/OFF
(1)
Display OFF Turn display on Calibrate the sensor
mode
Device is on Calibrate the sensor
Regular Switch between colour palettes
UP
(2)
Menu navigation
MENU
Enter quick menu
Regular
M
(3)
Menu navigation
Regular Control discrete digital zoom
DOWN
(5)
Menu navigation
Navigation downwards/leftwards
REC Video Start video
(4) recording
Photo Take a photograph
OTHER SHORT LONG PRESS
PRESSES
Turn display off/
Power device off
Wi-Fi on/off
Navigation upwards/rightwards
Enter main menu
----
Confirm selection
PiP on/off
Pause / resume video Stop video recording /
recording Switch to photo mode
Switch to video mode
