Do as follows to switch off the gas heating.
1 Press the button with the arrow
until the gas heating symbol
flashes. The "ON" text is shown
next to the temperature on the
display.
blinkar
flashes
7. Heating with electricity
To activate heating with electricity. The greater the power the more rapid the heating will be.
1 Press the button with the arrow
until the electrical heating symbol
flashes. The "OFF" text is shown
next to the temperature on the
display.
blinkar
flashes
Do as follows to switch off heating with electricity.
1 Press the button with the arrow
until the electrical heating symbol
flashes.
blinkar
flashes

8. Circulation pump

This symbol is displayed when the circulation pump is operating (12V-
pump or 230V-pump).
When heating is required in the vehicle, the pump starts automatically.
The boiler selects the 230V pump if one is installed in the system. When
the 230V is disconnected from the vehicle the 12V pump is automatically
selected. The symbol will light up even if the pump is defective.
9. 30V connection
This symbol lights up when 230V is connected to the
vehicle.
 Switch off the gas heating by
pressing the -/Off button. The
"OFF" text is shown next to the
temperature on the display.
blinkar
flashes
 Select power (1kW, 2kW or 3kW)
with the +/On or -/Off buttons.
The diagram shows that 3kW
power has been selected (some
boilers are only equipped with
1-2kW).
blinkar
flashes
 Switch off the electrical heating
by pressing the -/Off button until
all power steps have gone out.
The "OFF" text is shown next to
the temperature on the display.
GB
3 The gas heating symbol goes
out when the panel returns to
standby.
3 The electrical heating symbol is
shown when the panel returns to
standby.
3 The electrical heating symbol
goes out when the panel returns
to standby.
7
