Technical Data - Alde Compact 3010 Betriebsanleitung Und Installationsanleitung

These instructions deal with the
installation and assembly of boiler,
control panel and expansion tank.
On Alde's homepage, www.alde.se,
under the heading "Heating Technic",
there are recommendations regarding
water-borne heating systems.
Read these instructions carefully
before assembling the boiler.
These instructions have been approved
for the Alde Compact 3010 boiler, assem-
bled in caravans, campers and buildings,
in accordance with CE no 0845 BP-0003
and EMC e5 02 0136.
Installation and repairs may only be car-
ried out by a professional. National regu-
lations must be adhered to.

TECHNICAL DATA

Measurements/Weight:
Boiler height: 310 mm
Boiler depth: 340 mm
Boiler width: 490 mm
Weight: 14 kg (without fluid)
Gas: Propane
Output 1: 3,3 kW
Consumption: 245 g/h
Output 2: 5,5 kW
Consumption: 405 g/h
Pressure: I 28-30/37 mbar
3+
I 30 mbar
3B/P
Volume/Pressure/Temp.
Liquid volume radiator water: 3,5 liter
Liquid volume warm water:
Max pressure radiator water: 0,05 MPa
Max pressure warm water:
System temperature:
30 V ~
Output element:
Output element (2 or 3 kW): 1 x 2100 W
1 V DC
Current consump.: 1 amp (max)
Fuse: 3.15 amp+/3.15 amp-
INSTALLATION OF BOILER
The boiler can appropriately be located
in a wardrobe or storage space, but can
also be located under the floor of the
vehicle. If located outside the vehicle,
the boiler should be built into an enclo­
sed space so that it is protected against
splashing of water, exhaust gases, etc.
In choosing the location, consideration
should also be given to dismantling the
service hatch (A 1) and that space will be
available for replacement of components
during service. The data plate on the
boiler shall be legible after installation.
The measurements given in Fig. A for
building in are recommended minimum
measurements with mounting of the
boiler.
The space where the boiler is to be
assembled must be ventilated, with a
ventilation area of at least 70 cm2.
14
GB
The boiler shall be screwed down onto
the floor through the holes in the fixing
brackets (A 2).
NB ! The boiler must not be located in the
passenger area of a vehicle of type M2 or
M3 respectively.
Fig A.
1. Service panel
. Holes for screwing down
MOUNTING OF ROOF FLUE
The boiler may only be mounted with
the original flue. The flue must not be
blocked.
The roof flue should be mounted on a
level base, (however, a maximum of 30º
roof slope). Objects must not be mounted
on the roof within a radius of 200mm from
the flue.
Mark the centre of the location where the
flue is to be mounted, or drill a Ø 76mm
hole through the roof.
Mount the flue from the outside of the
roof. Seal between mounting washer (C
4) and roof (C 5) with sealing compound
Butane
for automobile body application, and
3,8 kW
screw down the flue with 6 plate screws
275 g/h
(C 6).
6,4 kW
460 g/h MOUNTING OF WALL FLUE
The boiler may only be mounted with
the original flue. The flue must not be
blocked.
The wall flue should be mounted on as
8,4 liter
flat a surface as possible, and also so
that air can freely circulate past the flue.
(0,5 bar)
The flue should not be mounted closer
0,3 MPa
than 300mm sideways on from an ope­
(3,0 bar)
ning window or ventilation inlet.
max 85°C.
A flue must not be mounted under a
window that can be opened, or a ventila­
tion inlet, see drawing.
1 x 1050 W
If the flue is mounted closer than the
measurements given above, a window
circuit-breaker shall be installed that
shuts off the LPG gas supply when the
window is open.
Prohibited zone
NOTE that current national regulations
must be followed.
The distance from the flue to ventilation
inlet under the vehicle must be at least
300mm (not a legal requirement).
The distance from flue to refilling position
or ventilation for fuel shall be at least
500mm.
Mark the place where the flue is to
be located. Then drill a Ø 83mm hole
through the outer wall. First mount the
gasket (B 7) and then screw down the
flue (B 8) with the 6 plate screws (B 9).
If the surface is structured, of ball-ham­
mered plate type, sealing compound for
automobile application must be used
with the gasket. Note that the flue shall
be mounted with the bend upwards,
(the roof flue is also marked TOP
OBEN). After that, mount the plastic
cap (B 10a) and the O ring (B 10b) with
the accompanying two screws (B 11).
MOUNTING OF INLET/
EXHAUST HOSE
Hose length with roof flue: min. 2.0 and
max. 3.5m.
Hose length with wall flue: min. 0.5 and
max. 2.0 m.
Measure and cut the required length of
inlet hose (Ø 75mm). The exhaust hose
(Ø 50mm) should be cut so that it is
30mm shorter than the inlet hose.
Note that the hoses will go on to the
hose sleeves 20mm.
Push the exhaust hose into the inlet
hose. First mount the exhaust hose
(B,C 12) on the flue and tighten it with a
hose clip ( B,C 13).
Then put on the inlet hose (B,C 14) and
tighten with the other hose clip (B,C
15). After that, mount the hoses in the
same way on the boiler. Staple the hose
(B 16) on c/c 600mm or equivalent.
NB! Check the lay to ensure that water
cannot be retained in the inlet/exhaust
hose.
MOUNTING OF CONTROL
PANEL
Adjust the location of the control panel
with reference to the length of the cable
between the boiler and the panel.
The control panel should be located at
least 1 metre above the floor, but not
too high towards the ceiling. Nor should
Window
it be located on an outer wall or close to
objects that give off heat, for example,
CD player, refrigerator or lamps, as this
can give incorrect indication of tempe­
rature.
If, nevertheless, the control panel must
be, or has been, mounted in the vicinity
of objects that emit heat, an external
temperature sensor should be con­
nected to the control panel.
For making holes, see the accompany­
ing instructions in the panel's
packaging.
