CONTROL PANEL – FUNCTIONS AND SyMBOLS
(Applies to control panels with program version 38 (06-17) or later, see item 17)
0. The standby and on-position of the control panel
In standby, the functions which are activated in the
boiler are shown, and there is no background lighting
in the display. The control panel automatically goes to
standby from the on position after two minutes if no
buttons are pushed or if you step to standby (left of
On/Off) with the arrow keys.
1 The control panel is on standby
and the heater is switched off.

1. Resetting the system

1 Press the Store/Reset button for
10 seconds. The control panel is
reset to the factory setting.
. Start the heater
Start the heating in the caravan with the settings last
used.
1 Press the button with the arrow
until "Off" (main breaker) in the
display flashes.
blinkar
flashes
3. Switch off the heater
1 Press the button with the arrow
until "On" (main breaker) in the
display flashes.
blinkar
flashes
Start the on position by pressing any button.
The background lighting comes on (blue light) and
a function that can be set flashes. Select a function
that can be set with the arrow keys. The settings are
automatically saved.
 The control panel is on standby
and the heater is operating.
 The main breaker to the control
panel is in the "Off" position,
Gas is on, Electricity at 1kW and
22°C.
If you break the power to the heater, the settings which
were last used will automatically be used when the
power comes back on.
 Press the +/On button."On"
(main breaker) in the display
flashes.
blinkar
flashes
 Press the -/Off button. "Off" (main
breaker) in the display flashes.
blinkar
flashes
GB
The pump is in automatic
position. The lower menu row is
not lit up.
3 The settings are ready."On"
(main breaker) is shown in the
display when the panel returns to
standby.
3 The settings are ready. "Off"
(main breaker) is shown in the
display when the panel returns to
standby.
5
