MEANINGS OF SYMBOLS

NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning before use.
It is important that you read, fully understand and
observe the
warnings. Careless or improper use of the unit may
cause serious or fatal injury.
Read, understand and follow all warnings and
instructions in this manual and on the unit.
Always wear eye, head and ear protectors when using
this unit.
Warning, kickback danger. Be careful of possible
sudden and accidental upward and/or backward
motion of the guide bar.
One-handed usage not permitted. While cutting, hold
chain saw fi rmly with both hands with thumb fi rmly
locked around front handle.
Chain brake
Choke - Run position (Open)
Choke - Start position (Closed)
On/Start
Off /Stop
Contents
WHAT IS WHAT? .............................................................................. 7
WARNINGS AND SAFETY INSTRUCTIONS .................................. 8
SPECIFICATIONS .......................................................................... 10
ASSEMBLY PROCEDURES ........................................................... 11
OPERATING PROCEDURES ......................................................... 11
MAINTENANCE .............................................................................. 13
Parts breakdown
6
(Original instructions)
following safety precautions and
Emergency stop
Fuel and oil mixture
Chain oil fi ll
Carburetor adjustment - Idle speed
Carburetor adjustment - Low speed mixture
Carburetor adjustment - High speed mixture
Priming pump
Guaranteed Sound power level
4
Hot surface
Oil pump adjustment
