The Login window will appear. The user name is admin. The password can be
found at the bottom side of the housing (Web-interface) or on the last page of
this manual.
Web-Inter. admin XxXxXxXxX
WLAN-AP -
SSH
Î Enter admin in the User name field.
Î Enter the password in the Password field.
Î Click the Login button.
7.2

Menu overview

Main menu Submenu Function
Status Status Display general device information
Display connection state
Display remote access over Internet
Display LAN / WLAN information
Display access point information
Configuration General Change general configuration
Firmware update configuration
Network Change LAN configuration
Change WLAN settings
Change WLAN STA settings
Change access point settings
Remote access VBus.net access over local network
Configure remote access over Internet
Users Change the password
About General Order Communication module open source software
Powered by Display the open source applications and libraries used
History Display firmware updates
Links Useful links
32
xxxxxxxx
root xXxXXXX
7.3

Displaying general device information

In order to display general device information, proceed as follows:
Î Click the Status main menu.
The following information will be displayed in Status:
• Device name
• Current date and time settings of the Communication module
• Device uptime
• Device serial number
• Firmware version
• Device connected
• Support Report
7.4

Displaying the connection state

In order to display the connection state, proceed as follows:
Î Click the Status main menu.
The following information will be displayed in Connection state:
• Local network accessible
• Internet accessible
• Web portal enabled
• Online status
7.5

Displaying remote access over Internet

In order to display the status of the remote access via Internet, proceed as follows:
Î Click the Status main menu.
The following information will be displayed in Remote access over Internet:
• Owner e-mail address
• Token
7.6 Displaying network configuration information
In order to display the network configuration, proceed as follows:
Î Click the Status main menu.
The following information will be displayed in LAN:
• IP address
• MAC address
