Application examples

4 application examples will be described and corresponding chapters be indicated
in the following.
Configuration for RPT (see chap. 5.1 on page 29)
1. Direct connection via WLAN (service access) (see chap. 5.1.1 on page 29)
Communication module –
device
Internal WLAN access point
2. Connection in the home network (see chap. 5.1.2 on page 29)
device
Communication
module
28
• RPT
• Web interface
Router
• RPT
• Web interface
Configuration for VBus.net (see chap. 5.2 on page 30)
3. WLAN connection to VBus.net (internet access) (see chap. 5.2.1 on page 30)
device
Communication
module
4. LAN connection to VBus.net (internet access) (see chap. 5.2.2 on page 30)
device Communication
module
Router
www
• VBus.net
Internet / VBus.net • RPT
• Web interface
Router
• VBus.net
www
• RPT
Internet / VBus.net • Web interface
