Before working on the spray gun remove the power plug from the socket.
•
Cover areas that are
may transport paint mist over great distances and cause damage.
•
The units may only be used with a functional valve.
hose (Fig. 12 A, item 14) do not operate the unit further! Dismantle and clean the
ventilating hose, valve and diaphragm and replace the diaphragm if necessary.
•
Do not lay the spray gun.
•
The device is equipped with a thermal release which disconnects the device in case of
overheating. In this case, turn off the device, remove the plug and let the device cool
down for at least 1/2 hour. Eliminate the cause of heating, e.g. bent hose, soiled air filter,
slots for air intake covered.
With original WAGNER accessories and spare parts, you have the guarantee that all
safety regulations are fulfilled.
Max. viscosity
Max. flow rate
Power source
Power consumption
Atomizing output:
Double insulation
Sound pressure level
Oscillation level
Air hose length
Weight
1)
Air cap
3)
Union nut
5)
Trigger guard
7)
Gun handle
9)
ON/OFF switch
11)
Frame
13)
Frame cover/ Gun holder
15)
Fastening belts for air hose
17)
Basic device closure
19)
Air hose connection
21)
Basic device
23)
Container
25)
Ventilating hose
27)
Deposition tray for hardware
29)
Air filter
31)
Power cable
33)
Deposition tray for spray attachments
16
16
not to be sprayed. When working keep in mind that wind, for example,
Technical Data
170 DIN-s
240 g/min
230 - 240 V
570 W
130 W
80 dB (A)
< 2,5 m/s
7,5 m
13,6 kg
Description (Figs. 1+2)
If paints rises in the ventilating
~
TechnDat_GB
2)
Tip
4)
Standard spray attachment
6)
Material volume regulation
8)
Air volume control
10)
Air hose
12)
Frame carry handle
14)
Air hose retainer
16)
Basic device cover
18)
Main switch
20)
Frame base
22)
Frame closure
24)
Valve
26)
Fastener for radiator/detail spray
attachment (accessory
28)
Cover of air filter compartment
30)
Cable grommet
32)
Rubber band
