order codes:
4114 = Universal transmitter
4501 = display / programming front
5910 = CjC connector
electrical specifications:
Specifications.range. . .................................... -20°C.to.+60°C
Common specifications:
Supply.voltage,.universal.............................. 21.6...253.VAC,.50...60.Hz.or
.
Max..consumption........................................ ≤.2.0.W
Fuse. . ............................................................. 400.mA.SB./.250.VAC
Isolation.voltage,.test./.operation................. 2.3.kVAC./.250.VAC
Communications.interface............................ Programming.front.4501
Signal./.noise.ratio........................................ Min..60.dB.(0...100.kHz)
Response.time.(0...90%,.100...10%):.
. Temperature.input..................................... ≤ 1.s
. mA./.V.input.............................................. ≤ 400.ms
Calibration.temperature................................ 20...28°C
Accuracy,.the.greater.of.the.general.and.basic.values:
General.values
Input. Absolute.
type accuracy
≤.±0.1%.of.span
All
Basic.values
Input. Basic.
type accuracy
≤.±4.µA
mA
≤.±20.µV
Volt
Pt100 ≤.±0.2°C
≤.±0.1.Ω
Linear.resistance
≤.±0.1.Ω
Potentiometer
TC.type:. .
E,.J,.K,.L,.N,.T,.U ≤.±1°C
TC.type:.R,.S,.W3,. .
≤.±2°C
W5,.LR
TC.type:.B.
≤.±4.5°C
160...400°C
TC.type:.B.
≤.±2°C
400...1820°C
34
19.2...300.VDC
Temperature.
coefficient
≤.±0.01%.of.span./.°C.
Temperature.
coefficient
≤.±0.4.µA./.°C
≤.±2.µV./.°C
≤.±0.01°C./.°C
≤.±0.01.Ω./.°C
≤.±0.01.Ω./.°C
.
≤.±0.05°C./.°C
.
≤.±0.2°C./.°C
≤.±0.45°C./.°C
≤.±0.2°C./.°C
EMC.immunity.influence....................................... <.±0.5%.of.span
Extended.EMC.immunity:.
NAMUR.NE.21,.A.criterion,.burst......................... <.±1%.of.span
Auxiliary.supplies:
2-wire.supply.(terminal.44...43). . ................... 25...16.VDC./.0...20.mA
Max..wire.size. . .............................................. 1.x.2.5.mm
Screw.terminal.torque................................... 0.5.Nm
Relative.humidity........................................... <.95%.RH.(non-cond.)
Dimensions,.without.display.front.(HxBxD).... 109.x.23.5.x.104.mm
Dimensions,.with.display.front.(HxBxD). . ...... 109.x.23.5.x.116.mm
Protection.degree. . ........................................ IP20
Weight........................................................... 145.g./.160.g.with.4501
rTd, linear resistance and potentiometer input:
Input. Min..
type value
Pt100. -200°C. +850°C.
Ni100. -60°C. +250°C.
Lin..R. 0.Ω 10000.Ω
Potentiometer 10.Ω 100.kΩ
Input.for.RTD.types:.
. Pt10,.Pt20,.Pt50,.Pt100,.Pt200,.Pt250,.Pt300,.Pt400,.Pt500,.Pt1000.
. Ni50,.Ni100,.Ni120,.Ni1000.
Cable.resistance.per.wire.(max.),.RTD. . ........ 50.Ω
Sensor.current,.RTD. . .................................... Nom..0.2.mA
Effect.of.sensor.cable.resistance
(3-./.4-wire),.RTD. . ......................................... <.0.002.Ω./.Ω
Sensor.error.detection,.RTD......................... Yes
Short.circuit.detection,.RTD. . ........................ <.15.Ω
2 .stranded.wire
Max.. .
value Standard
IEC60751.
DIN.43760.
-.
-
35
