Accessories and spare parts

3.
Accessories and spare parts
Accessories and spare parts
Wireless thermostat "R-Tronic RT B"
(ENOCEAN)
Wireless thermostat "R-Tronic RTF
B" (ENOCEAN)
Wireless actuator "Aktor MH CON
B" (ENOCEAN)
Thermostatic radiator valve with
"Q-Tech" technology
(flow range 10 - 170 l/h)
4.

Installation

4.1

"R-Tronic RT B" (ENOCEAN), "R-Tronic RTF B" (ENOCEAN)

f Select an installation location and type of installation and connect the
wireless thermostat to the power supply as described in the "Operating
instructions" supplied with the wireless thermostat.
4.2

Preparation hydronic balancing OVbalance

Further components are required for the electronic hydronic balancing of
your heating system.
f Equip each terminal unit (radiator) of your heating system with the
following components:
• Oventrop thermostatic radiator valve with "Q-Tech" technology (flow
range 10 - 170 l/h)
• Wireless actuator "Aktor MH CON B" (ENOCEAN)
f Set the valves with "Q-Tech" to presetting 17 (170 l/h) for a maximum
flow rate.
Installation and setting must be carried out by a sanitary, heating
and air-conditioning specialist.
18
"OVbalance Home" Basic set
Item number
1150780
1150781
1150766
1150765 not suitable
various
115079081-V01.08.2018
