Temperature Sensor; Pressure Sensor - Comprag A0708 Bedienungsanleitung

4
5
3
2
1
Fig. 2.2 Function diagram AR07..-AR22.., ARD07..-ARD22..
Air flow
Oil flow
Air/Oil mix flow
Main components
1 Electric motor
2 Belt drive
3 Air end
4 Air filter
5 Intake valve
6 Air-Oil separation tank
7 Safety valve
8 Air-Oil separator
9 Throttle valve
10 Non-return valve
11 Min. Pressure valve
12
Р
10
9
6
т
16
15
14
13
22
12
11
8
17
7
18
19
17
12
13
14
15
16
17
18
19
20
21
22
7
21
20

Temperature sensor

Pressure sensor

Pneumatic control line
Non-return valve
Heat-exchanger, Air section
Heat-exchanger, Oil section
Thermostatic valve
Oil filter
Drain valve
Oil filling plug
Oil level sight glass
Air outlet valve
Refrigerated dryer (ARD only)
Pressure vessel
Version 1.2
