Main components
К1, K2, К3, К4 Contactor
М1 Electric motor
Т Temperature sensor
SB Emergency stop
F1, F2 Fuses
МКС Phase sequence relay

2.7 Electrical connection values

Voltage (V) Frequency (Hz)
400
380
380-400
380-400

3. Start up

3.1 Lifting and carrying

For transport with a forklift truck, use the rigging holes in the frame.
The compressor has slotted rigging holes with width C – fig. 3.1.
Move the compressor carefully.
16
A07..
50 2,5/4
50 2,5/4
50 35
Motor overload relay (A)
50 15,5
All lifting should be carried out using a forklift truck with a carrying
capacity suited to the compressor.
Lifting may be carried out with loading cranes, winches and other
machinery, using a crossbeam with the right length.
Local safety guidelines for lifting have to be observed.
YA
R
I/P
TN1, TN2
TR
QS
A11..
Cable size (mm²)
4/6
4/6
Fuse value (A)
35
12,7
Solenoid valve
Electronic controller
Pressure sensor
Overload relay
Transformer
Automatic power switch
A15.. A18..
6/10 10/16
10/10 10/16
50 63
16,7 20,2
A22..
10/16
16/16
63
23,7
