Assembly Notes - BRAWA H0 – 6341 Aufbau- Und Bedienungsanleitung

Construction- and operating Instructions
Mountain- and Valley Station H0 – 6341
Index of contens

1. Assembly Notes ......................................................... 2

2. Building types ............................................................ 2
3. Assembly – Valley Station ......................................... 3
4. Assembly – Mountain Station .................................... 4
5. Spare Parts List ......................................................... 5
1. Assembly Notes
Before starting on the assembly of your cableway, we'd like
to draw your attention to familiarity with these Operating
Instructions and each individual step in assembly and
operation being in the correct sequence (1, 2, 3)
and adherence to same being essential to proper and safe
operation of the model cableway.
Please read the appropriate part of these Instruction
through thoroughly and carefully before undertaking each
step. Make sure you have studied the diagram/s and know
exactly where each individual part has to be installed and/
or assembled.
The part numbers are given on the component holders.
Various modules are pre-assembled and have no part no.
The pre-assembled component/module can then be found
by using the illustration/s provided for the purpose.
Those components that have to be installed using adhesive
are to be so installed using a polystyrene adhesive and
applying same sparingly. Make sure of siting before final
gluing of any component in place and ensure it can
function as it should.
Grooves, slits and holes are provided to aid you in fixing
many parts in place and ensure proper surface component
fit via rigid connection. If adhesions are not rugged enough
for their purpose, the surfaces to be glued together can be
roughened with sandpaper or a fine file.
The building construction set allows you to build one type
each of the mountain and valley station.
Side
2. Building types
The mountain and valley station buildings can be built as
two different types depending on the available space.
Type 1
If there is too little space for the building (building floor
space), the main building can be built without the
restaurant part (see page 3).
Type 2
If there is enough space, the main building can be built
with the restaurant building (see page 3).
Note:
The cableway to this building set is available as an option
under the Order no. 6340.
We want you to enjoy constructing this building set.
