Installing the Wall-mount Brackets

• When installing the wall-mount brackets to the LCD color TV, place the LCD color TV face
down on a soft cloth or cushion.
• The stand can also be removed from Model 52 when it is in the standing position, but the
Caution
explanation is given for the laying position for which it is easier to install the wall-mount
brackets.
• When lifting up the television, do not hold it by the speakers. Doing so could damage them.
Remove the table stand.
1
Remove the screws (4 screws) fastening the table stand, and then remove the table stand.
(Remove after pulling in the direction shown by the arrow.)
Save the removed stand fastening screws (4 screws).
Perform the cable work.
2
Remove the terminal cover, wire the cables, and then replace the cover.
E-7
