Commissioning / Operation
Make sure that the voltage indicated on the
●
identification plate is the same as that available in the
building and that the socket has an earth wire. The
machine is to be connected to a 230V 1N-, 16A socket.
Depending on working location, equip machine with
●
its best possible vacuum-combination. Because of
the two fixed wheels the machine is easy to
transport inside the staircase.
When used as a water vacuum cleaner, the float
insert (j) must always be inserted into the water
tank before the appliance is put into operation; the
Large area filter (k) and Dustbags (m) must be removed.
1.
Equipment as a water vacuum cleaner
with flexible nozzle
In no case shall be drawn with large surface filter
or paper filter bag water. Capital losses can result.
☞
m
6
7
3
☞
j
☞
k
☞
b
a
● The use float (j) is prevented by
☞ Suction hose (b) with the sliding
4
8
☞ The stainless steel tubes (c)
b
☞ Wrap
c
9
3
☞ Now you may proceed with
d
2.
Conversion to a dust vacuum cleaner
☞
m
6
7
3
☞
k
☞
j
☞
Place the motor housing (7) back into position and
☞
adjust by pressing the latch (6) back into the securing
position.
SW 50 - Englisch
Sucker off (3). Locking handle
(6) after press up and suction
head (7) decrease.
Large surface filter (k) if and
remove dust bag (m).
Insert the float ( j ).
Place the motor housing (7) back
into position and adjust by
pressing the latch (6) back into
the securing position.
suction automatic elimination of
overflow water tank.
connector (a) on the sliding
clutch (4) of the dust and dirt
water tank connected (8).
together and connect to the
suction hose (b).
the
power
cord
completely. Install the required
accessories (eg water suction
(d).
vacuum cleaning by pressing
the
main
switch
(3)
Sucker off (3). Locking handle
(6) after press up and suction
head (7) decrease.
Float insert (j) take out and use
large area filter (k).
For reasons of hygiene, it is
advisable to employ a paper
filter bag (m).
Never vacuum clean without
large filter surface.
Depending on working location, equip machine with its
☞
best possible vacuum-combination (e, f, g or h).
3.
Emptying the tank
Suction on / off switch (3) Turn off and unplug it.
☞
After an operation, you go to empty the vacuum
☞
cleaner to a waste disposal or toilet.
Locking handle (6) after press up and suction
☞
head (7) decrease.
Saugschlauch am Staub-und Schmutzwasserbehälter
☞
abnehmen.
Float insert (j) take out.
☞
Waste water tank emptied by tilting.
☞
Suction hose to the dust and dirt water tanks
☞
reconnect.
Place the motor housing (7) back into position and
☞
adjust by pressing the latch (6) back into the securing
position.
The appliance is ready again for operation.
☞
4.
Dirt Water emptying with drain hose
14
X
13
After finishing the cap (14) must be screwed
hermetically.
5.
Importand instructions for maintenance
Motor housing (7) carefully on tank (8) so a tight seal is
●
ensured.
Check seal on the suction head at regular intervalls.
●
After use, clean float insert (j) and Tank (8).
●
Keep wheels clean (11) and lightly oil or grease as
●
required.
Shake out dust filter (k) - do not wash.
●
(9)
6.
Information on commissioning, use and
maintenance
If the appliance used commercially, it should only be
●
operated
by
The cleaner must be protected with a circuit breaker of
●
on.
the type "L" with a rated current of 10 A or fuse 10 A.
When used as a water vacuum cleaner, the float unit
●
must always be inserted into the water container
before appliance is into operation.
In order to clean and maintain the machine, replace
●
parts or convert to alternative functioning, the motor
should be switched off and the plug removed from the
mains socket.
The mains cable must not be damaged by running
●
over it, crushing or similar activities. It should be
regulary checked for signs of damage or ageing. If ist
condition is not impeccable, the machine should not
be used.
When employing or replacing connection or extensi-
●
on cables, one must adhere strictly to the instructions
of the appliance manufacturer.
Remove drain hose (13) from the
☞
support.
Unscrew cap (14).
☞
Emptying the tank (8).
☞
persons
instructed
in
use.
8
