Area PowerSet Description Capacity
15.6 m² PowerSet 2.0-170-1p
18.2 m² PowerSet 2.4-170-1p
23.4 m² PowerSet 3.0-165-1p
23.4 m² PowerSet 3.1-170-1p
23.4 m² PowerSet 3.1-170-3p
26.0 m² PowerSet 3.4-170-1p
27.3 m² PowerSet 3.6-170-1p
31.2 m² PowerSet 4.0-165-1p
31.2 m² PowerSet 4.1-170-1p 4.08 kWp 24 x SF170-S 1 x Turbo 1P
31.2 m² PowerSet 4.1-170-3p 4.08 kWp 24 x SF170-S 1 x Turbo 3P1
PowerSet 4.8-170-1p 4.76 kWp 28 x SF170-S 1 x Turbo 1P
36.4 m²
39.0 m² PowerSet 5.1-170-3p 5.10 kWp 30 x SF170-S 1 x Turbo 3P2
45.5 m² PowerSet 6.0-170-3p 5.95 kWp 35 x SF170-S 1 x Turbo 3P2
54.6 m² PowerSet 7.1-170-3p 7.14 kWp 42 x SF170-S 1 x Turbo 3P2
62.4 m² PowerSet 8.2-170-1p 8.16 kWp 48 x SF170-S 2 x Turbo 1P
The following are not included: mounting structure and clamps; mounting tool and cable assembly tool; data logger.
Schematic structure based on PowerSet example 3.1
4.

About this Manual

4.1 Contents
These instructions contain all information required by a technical professional for
setting up and operating the inverters.
When installing other components (e.g., AC cable, mounting system) follow the
manufacturer's instructions.

4.2 Target audience

Unless otherwise indicated, the target audiences of this manual are technical
professionals and system operators.
Technical professionals are persons who, for example:
• have the knowledge of terminology and the skills necessary for setting up and
operating photovoltaic systems;
•
because of their professional training, knowledge and experience and know-
ledge of the relevant regulations can assess the following tasks and recognise
possible dangers:
- mounting electrical devices
- assembling and connecting data cables
- assembling and connecting power supply cables.
Modules Inverters
2.04 kWp 12 x SF170-S 1 x Turbo 1P
2.38 kWp 14 x SF170-S 1 x Turbo 1P
2.97 kWp 18 x SF165-S 1 x Turbo 1P
3.06 kWp 18 x SF170-S 1 x Turbo 1P
3.06 kWp 18 x SF170-S 1 x Turbo 3P1
3.40 kWp 20 x SF170-S 1 x Turbo 1P
3.57 kWp 21 x SF170-S 1 x Turbo 1P
3.96 kWp 24 x SF165-S 1 x Turbo 1P
Grid
connection Connecting cable
1ph 1 x 2(+) & 1 x 2(-)
1ph 1 x 2(+) & 1 x 2(-)
1ph 1 x 3(+) & 1 x 3(-)
1ph 1 x 3(+) & 1 x 3(-)
3ph 1 x 3(+) & 1 x 3(-)
1ph 1 x 4(+) & 1 x 4(-)
1ph 1 x 3(+) & 1 x 3(-)
1ph 1 x 4(+) & 1 x 4(-)
1ph 1 x 4(+) & 1 x 4(-)
3ph 1 x 4(+) & 1 x 4(-)
1ph 1 x 4(+) & 1 x 4(-)
3ph 1 x 5(+) & 1 x 5(-)
3ph 1 x 5(+) & 1 x 5(-)
3ph 1 x 6(+) & 1 x 6(-)
1ph 2 x 4(+) & 2 x 4(-)

4.3 Markings

4.3.1

Symbols

Symbol
General danger warning
Read manual before using the product.
Danger from hot surfaces
(only for Turbo 3P1 / 3P2 inverter)
4.3.2

Keywords

Keywords used in conjunction with the symbols described above:
Keyword Description
Danger
Immediate danger of death or serious bodily injury
Figure 3
Warning
Possible danger of death or serious bodily injury
Caution
Possible danger of light or medium bodily injury
Attention
Possible damage to property
Advice
Tips on operation or usage of the manual
4.3.3

Markings used in the text

Markings Description
√ Condition for action

Single step
1., 2., 3., ...
Several steps in series
cursive light emphasis
bold
strong emphasis
Designation of product elements such as buttons,
Courier
displays, operating state
3
DC Plugs & Modules
cable sockets in series
50 m 3 + 3 6
50 m 3 + 3 7
50 m 3 + 3 6
50 m 3 + 3 6
50 m 3 + 3 6
50 m 3 + 3 5
50 m 3 + 3 7
50 m 3 + 3 6
50 m 3 + 3 6
50 m 3 + 3 6
50 m 3 + 3 7
50 m 3 + 3 6
50 m 3 + 3 7
50 m 3 + 3 7
100 m 6 + 6 6
Description
Danger from electricity
Unlocking tool
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Location
Manual
Manual / device
Device
Manual / device
