8.

Transport and Storage

Pay attention to all advice on the packaging when storing or transporting SF Power-
Sets. A dry room should be chosen for storage. The packaging is not waterproof.
All electronic components should be kept away from liquids during transport and
storage. The SF PowerSets must remain in the original packaging until the installation.
Small amounts of white powder from packaging material may adhere to the mo-
dules. This may safely be ignored and has no affect on performance.
9.

Disposal

9.1

Disposal within the EU

This sign on the modules and inverters indicates that these
products must not be disposed of in household waste
when they reach the end of their life cycle.
For disposal and recycling, please take the products to
authorised collection points where you can hand them
over free of charge. Alternatively, in some countries you
may hand them in at the dealer's where you obtain your
replacement goods.
Please contact your local authority for further details on
your nearest authorised collection point.
The DC cables can be disposed of at municipal collection points as electric waste.
Penalties may be imposed for violation of the rules depending on the applicable law.

9.2 Disposal outside the EU

The symbol of a dustbin with a line through it is only valid in the European Union
(EU). If you want to dispose of your product please contact your local authority or
dealer to find out the correct disposal method.

10. Technical data and data sheets

10.1 Solar Frontier SF165-S/SF170-S photovoltaic modules
Electrical characteristics
2
Rated output Pmax
Open circuit Voc
voltage
Short circuit Isc
current
Rated voltage Vmpp
Rated current Impp
Rated output Pmax
Open circuit Voc
voltage
Short circuit Isc
current
Rated voltage Vmpp
Rated current Impp
*1 Data measured under standard test conditions (STC) defined by the IEC standard
454 5
(1000 W/m² irradiance, 25 °C module temperature, AM 1 5 with tolerances of ±10% for
25 1 1
72 5
31
±
Isc and Voc and +10% / -5% for Pmax). The module efficiency with 200 W/m² irradiance is
d
typically 98% (±1.9%) of the STC efficiency.
*2 Nominal operating cell temperature (NOCT): Module operating temperature with 800 W/m2
6 6
irradiance, 20 °C air temperature, 1 m/s wind speed and in the open circuit condition. gebohrung
,
Thermal characteristics
NOCT
Temperature-coefficient Isc
Temperature-coefficient Voc
Temperature-coefficient Pmax
1 20
Characteristics for system design
Maximum system voltage
Limiting reverse current
Maximum series fuse rating
Standard test conditions (STC)*1
Module SF165-S Module SF170-S
57
±2
165 W 170 W
110 V 112 V
2.20 A 2.20 A
85.5 V 87.5 V
1.93 A 1.95 A
Nominal operating
cell temperature (NOCT)*2
Module SF165-S Module SF170-S
123 W 126 W
100 V 102 V
1.76 A 1.76 A
80.2 V 82.1 V
12
1 5
5
1.53 A 1.55 A
5 5 5 5
225 37 5
72,5
30
ø
5 8 6
Montagebohrung Mon agebohrung
47 °C
α +0.01%/K
β -0.30%/K
δ %-0.31%/K
4 5
Vsys 1,000 V DC
Ir
Isf
Mechanical Data
Dimensions (L x W x H)
Weight
Module operating temperature
Application class
as per IEC 61730
Fire safety class
as per IEC 61730
Cable
Snow load (to the front of the module)
Wind load (to the back of the module)
Module drawing
(7) 20
31 225
±1
(50) 150
13,5
30
No. Item
1 Cell
2 Cover glass
3 Encapsulant
4 Back sheet
5 Frame
6 Edge sealant
7 Junction box
8 Cable
9 Adhesive
10 Label
7 A
11 Screw
4 A
12 Bar code label
15
1,257 x 977 x 35 mm
(49.5 x 38.5 x 1.4 in)
20.0 kg (44.1 lbs) / 16.3 kg/m2
(3.3 lbs/ft2)
-40 °C to 85 °C
2.5 mm / AWG14 (halogen free)
2
2,400 Pa (IEC61646) / 1,600 Pa design
load (UL1703)
2,400 Pa (IEC61646) / 1,600 Pa design
load (UL1703)
1,257 ±2
431.5
±5
440
±5
454.5 454.5
372.5
372.5
ø
2 x 4
2 x
Grounding
ø ø
4 x 8.5 4 x 6.6
Mounting holes Mounting holes
13.7
33.5
86.6 1,200
±100
ø
2 x 4.5
465
±5
12
30
Qty Description
1 CIS on substrate glass
1 Clear tempered glass
EVA
Weatherproof plastic film / Colour:black and silver
1 Set Anodized aluminium alloy / Colour:black
Butyl rubber
1 With bypass diode
2.5 mm 2 (0.004 in²) / AWG14 (with waterproof
plug, MC4-compatible)
Silicon
1 Product label
8 Stainless tapping (SUS304J3)
1 Serial number
Class A
Class C
225 31
±1
