OPERATION

DISPLAY MAIN DISPLAY
After switching on the power amplifier, the greeting "Welcome" is displayed briefly. The main display then appears with the following
information: amplifier name (editable), amplifier channel (CH A - D) with links, speaker preset, audio level with peak indicator and channel
mute. Following about 10 minutes of no input, sections of the display fade out and only amplifier channel with links, audio level meter with
peak display and channel mute are displayed.
Amplifier name
Amplifier channel
with links
Speaker preset
CHANNEL VOLUME
Menu item for setting channel volume. Press the rotary MENUdial to access the selection menu for device settings, and turn the dial to
select the menu item CHANNEL VOLUME (bright background). Now press the dial and select the channel on which you want to adjust the
volume by turning the dial. Press the dial again and then turn it to set the desired volume (anticlockwise = reduce volume, anticlockwise
past -60dB, = mute, clockwise = increase volume). Press and hold the dial for about 2 seconds to mute or unmute the selected channel
(MUTE). To restore the volume of a muted channel to its previous unmuted level, turn the dial clockwise to increase the volume level slowly
and then press for about 2 seconds. Confirm your entry by pressing the dial. Repeat this procedure to set the desired volume level for the
other channels. To return to the selection menu, turn the dial to select the menu item CH VOLUME EXIT and confirm by pressing the dial.
Access the main display by turning the dial to select EXIT (light background) and confirm by pressing the dial. Following approximately 10
seconds of no input, the main display will appear automatically.

MASTER VOLUME

The overall volume can be set directly from the main display if this option has been activated in the appropriate menu item, and even if the
controls have been locked. Press the rotary MENUdial to access the selection menu for device settings and turn the dial to select the menu
item MASTER VOLUME (bright background). Press the dial twice then turn it to the left to select "ON" and confirm the entry by pressing the
dial (if the option to set overall volume is not available, select "OFF"). Turn the dial to select the arrow symbol and confirm by pressing the
dial to return to the selection menu. To return to the main display, turn the dial to select the menu item EXIT and confirm by pressing the
dial. Following approximately 10 seconds of no input, the main display will appear automatically.
Now you can adjust the overall volume level by turning the MENU dial in the desired direction, without having to press it beforehand
(anticlockwise = reduce volume, clockwise = increase volume). The display then changes to MASTER VOLUME (0 to 100). Following
approximately 2 seconds of no input, the main display will appear automatically.
6
Amplifier channel
with links
Audio level with peak indicator (PK)
and channel mute (mute)
Audio level with peak indicator (PK)
and channel mute (mute)
