Securing your child
Fig. 7 Should you wish to lengthen the belts, release the harness
buckle and lift the central adjuster at the front of the seat
and pull the shoulder harnesses forwards.
Pull the two buckle latches off the seat and the buckle
Fig. 8 forwards. Sit your child in the seat. Place the two buckle
latches together and then connect the visible metal part to
the buckle. Lock the system by tipping it forwards slightly.
An audible click will be heard.
Check that the belts are not twisted.
Fig. 9 Only if the harness straps are positioned correctly
and securely will your child have optimum protection.
Therefore the belt length should be correct when your
child wears different clothing. Tighten the sytem by pulling
the belt on the central adjuster.
Fig. 10 The pelvis belts pad should be located to ensure that it
covers the route of the pelvis belts, make sure the harness
is fi rmly adjusted.
Ensure that the cover does not become jammed beneath
the adjustment button so that the blocking function is not
impaired. To remove the child release the belt system by
pushing the red buttom.
TRIMAX belt and buckle padding
The car seat TRIMAX is supplied with a harness system
fixed on the back rest.
Fig. 10 When the child is secured with the 5-point central harness
the belt and buckle pads have to be correctly adjusted
to the child.
Selection of suitable shoulder strap height
The height of the shoulder straps must be adjusted to
the body size of the child. The belts should be threaded
through the slots in the back rests as close to the shoulder
height of the child as possible.
As a guide to this:
• Bottom shoulder strap slots for children up to approx.
1,5 years of age
• Middle shoulder strap slots for children up to approx.
2,5 years of age
• Top shoulder strap slots for children up to approx.
3,5 years of age
The pads are removed by pulling them over the belts
Fig. 11
and then disconnecting them from the yoke at the rear
of the seat.
To re-position the seat belt they have to be taken out
through the back rest. If you adjust the height of the seat
belts you also have to adjust the height position of the
pads to the same height.
Fig. 13 For conversion purposes, the belt pads in the backrest
are pulled out backwards.
Fig. 14 For installation the pads are pulled through the back rest
from the back afterwards the harness system has to be
thread through the belt pads and the back rest and be
reattached to the yoke at the back of the seat.
Fig. 15, 16 Please make sure that the seat belts are the same height
position and not twisted.
Recline position
Fig. 5, 6
The TRIMAX can be placed in a sitting or in a reclining
position, the reclined position is reached by pushing the
release bar downwards and pulling the seat in a forward
direction until it is firmly fixed.
To return to the upright position, push the adjusting handle
and slide the seat backwards.
