5.2 - CONNECTION TO THE WATER SUPPLY
1- The maximum temperature of the inlet water must not exceed 60°C (140°F).
2- Connect the water supply to the INLET port (D) by means of a reinforced hose (minimum
1,5 MPa - 15 bar - 200 psi) with internal diameter of no less than 13 mm. (1/2").
3- Since the water flow decreases according to the length of the hose, make sure that the quan-
tity of water supplied to the machine is not less than the quantities indicated in the chart
below.
4- The pressure of the inlet water must not exceed 1 MPa, 10 bar, 145 psi.
ATTENTION: The water supply which enters into the washer is not drinkable.
MODEL
8 90 - 8 70
• •
15 - 19 - 21
11 50 - 11 70
• •
10 100
•
If the user wishes to power the washer by means of free suction, simply emerge the end of the
supply tube in the water to be suctioned. The maximum suction depth considered as the dis-
tance in height between the water surface and the pump is 1m.
IMPORTANT
The water supplied to the machine must be clean. Running the unit without water, or with water
which is dirty, contains grit or corrosive liquids, causes serious damage to the machine.
FLOW RATE OF
WATER SUPPLY
L/min.
G.P .M. USA
2.9
11
15 4
D
9
