To go to the next press the ENTER button.
BLACK-OUT
In order that the channel loads a value upon the activation of BLACK-OUT, the JOG1 should be selected,
and then the open and closed black-out values of the channel should be selected with the JOG3 and JOG4
encoders. Any channel of a unit can be BO, either one or more, or all of them. In case of an RGB light the R,
G and B channels should also be given, otherwise no light will cease on the effect of the BO. Such a value is
worth being given in case of which the channel does not let any light out of the light.
To go to the next press the ENTER button.
RESET
If it is such a channel with which the unit can be reset, select the RESET here and then give the active value.
The same applies to the bulb as well. If your bulb can be switched on or off with the channel values, it shall
be selected here and the ON and OFF values should be given. The OFF values can be given by holding the
SHIFT button pressed.
To go to the next press the ENTER button.
DEFAULT, POSITION
A default value should be given to each channel of the unit. Upon turning on the controller the units will be
set up to these values, and upon pressing the DEFAULT button the selected units are set up to these default
values.
By selecting the POSITION and giving the value we will have a possibility to identify the unit where it is
located around the stage. Here it is worth selecting the intensity controlling channels (DIMMER, STROBO),
as well as crossing off the colours, figures from the image, i.e. in case of the COLOR and GOBO channels
white full circles are set. If in case of the STROBO channel a strobing value is given, the selected units will
be strobing upon pressing the POSITION bit (in the given case in a white full circle), so it will be easy to find
and identify it among the many units.
To go to the next press the ENTER button.
HEAD MOVEMENT
The control shall know which channels execute the mirror or head movement in the unit. When you reach the
channel during the adjustment, which adjusts the movement, select the PAN or TILT effect according to the
sense. Select the appropriate one with JOG1.
For going to the next press the ENTER button.
CHANNEL SELECTION
You have returned to the channel selection. Adding the new channel is possible with the NEW button.
Repeat the previous points as many times as many channels the light has.
If you have finished, you can exit with the ESC button. The controller asks about saving the modifications.
Pressing the ENTER button saves the modifications, you exit without saving upon pressing the ESC, while
you go back to the editing upon pressing any of the UP-DOWN buttons.
MENU - CUSTOMIZATION

SHIFT-BUTTON

The secondary functions of the buttons can be accessed in such a way that the SHIFT button is pressed and
hold pressed, and the wanted button is pressed additionally.
The SHIFT button can be used in several types of modes.
By holding pressed (during keeping the SHIFT button pressed the button should be pressed)
By automatic turning on and off (it is enough to press the SHIFT button for a short time, and it switches off
after pressing the button)
By turning on and off (upon pressing the SHIFT button the SHIFT mode switches on until it is pressed again.
Meanwhile only the secondary function of each button can be accessed.)
W1, UP-DOWN - selection from the possibilities
ESC - exit the menu item
25/28
00030698.DOC, Version 3.3
