JOG WHEELS (W1,W2,W3,W4)
The channels of the selected units can be set primarily with the JOG discs. Always the four channels related
to the current EFFECT button can be set with the JOG discs. The channels moved with the JOG disc get into
the manual and the programmer memories.
REGISTER POTENTIOMETERS (1-12)
With the REGISTER POTENTIOMETER some parameters of the 12 registers managed by the controller can
be set. One is always active from among the mode selecting buttons (RATE, WAIT, DELAY, DIMMER)
related to the register potentiometers, and the parameter related to the one that illuminates with full intensity
can be set with the potentiometers.
WAIT adjustment:
By switching to WAIT mode the image shifting time of the registers can be set between 0.10s -35-0s with the
potentiometers.
RATE adjustment:
By switching to RATE mode the floating time of the soft channels included in the registers can be set
between 0.10s -35.0s.
REGISTER BUTTONS (1-12)
With REGISTER BUTTONS the programs can be started or stopped in the 12 registers managed by the
controller. All the 12 registers have 10 pages (PAGE), on all of which a program can be saved, respectively.
Always the program of the current page can be started. If any of the LEDs illuminates with little intensity, it
indicates that there is a program image saved in the current page of the register. By pressing the button the
LED starts flashing, and the program saved on it starts running. By pressing the button again the program
running is stopped. If a program is started in one page, the program having run so far stops, and only the
newly started one will run. The programs located in the pages of one register substitute each other, while the
programs can be run in the different registers simultaneously.
By holding the SHIFT button pressed the data of the register related to the pressed buttons are shown in the
display, while in the monitor the data of all the 12 registers can be seen simultaneously.
REGISTER Page SHIFTING BUTTONS (up, down)
All the registers have 10 pages, on all of which programs can be saved. 12 registers x 10 pages = 120
programs. between the pages you can shift with the PAGE UP-DOWN buttons. The number of the current
page can be read in the seven segment display next to it.
REGISTER SELECTING BUTTONS (1-12 BLUE)
With the register group buttons (blue coloured: MUSIC, BPM, STOP, STEP) different running modes can be
selected in the registers. In order that the controller knows in which registers the activated event has to be
executed from 12, the registers have to be selected with these 12 blue buttons.
If the LED of the button illuminates with little intensity, the group is not selected, if the button is pressed, its
LED starts flashing, the group will be selected. By pressing it again the selection is ceased.
More registers can be selected simultaneously, if one of them is pressed and then another one is pressed in
addition, all those located between them switch to its state pressed at first.
MUSIC (BLUE)
The beats sensed by the controller can be monitored in the LED of the MUSIC button. By pressing the
MUSIC button the selected registers (blue buttons 1-12 with flashing LED) get into music mode. The
programs of the registers started in music mode the images are shifted in accordance with the beat of the
purchased music.
From music mode we can go over by selecting another mode (e.g. STEP) or moving the WAIT potentiometer
of the register.
