Description Of The Function - bürkert 8400 Bedienungsanleitung

9.8.

description of the function

Function Description of the function
EXT • To calibrate the expansion board in transmitters if it is activated (see Calibration Mode chap
Adjust the 4-20 mA output or the 4-20 mA input respectively:
→
Select
OUT
The transmitter generates a 4 mA current.
→
Using a multimeter, measure the current on the 4-20 mA output or input respectively.
→
Input this value in the function
→
Press ENTER to confirm.
The transmitter generates a 20 mA current.
→
Using a multimeter, measure the current on the 4-20 mA output or input respectively.
→
Input this value in the function
→
Confirm or do not confirm the input values by hitting "
SIM • To test the commutation thresholds by inputting a temperature value.
END • To go back to Read mode and display the temperature measured.
34
or respectively and confirm.
IN
.
OFFS
.
SPAN
english
Type 8400
Adjustmentandfunctionalities
" or " ".
YES OK NO OK
9.7) :
