Order data

Note
The GEMÜ 1436 cPos positioner can be directly or remotely mounted to linear or quarter turn actuators
For direct mounting the following components are required which must be ordered separately:
Linear actuators
Positioner GEMÜ 1436... ECON... 030/050/075
See order data - Positioner (direct mounting)
Mounting kit GEMÜ 1436 S01 Z...
See order data - Mounting kit for linear actuators
Connection kit GEMÜ 1219 000 Z...
See order data - Connection kit
Direct mounting
to linear actuator
GEMÜ 1436 S01Z...
Travel sensor mounting kit
GEMÜ 1219 000 Z....
Connection kit
1436 cPos eco
Direct mounting
A
B
C
GEMÜ 1436 cPos eco
Positioner
B
C
44 / 56
Quarter turn actuators
Positioner GEMÜ 1436... ECON... 090
See order data - Positioner (direct mounting)
Mounting kit GEMÜ 1436 PTAZ...
See order data - Mounting kit for quarter turn actuators
Connection kit GEMÜ 1219 000 Z...
See order data - Connection kit
Direct mounting
to quarter turn actuator
A
OPEN
ERROR
CLOSED
POWER
D
GEMÜ 1436 PTAZ
Travel sensor mounting kit
cPos 1436 Eco
A
D
C
