5

Electrical connections

Danger of cable break!
Turn electrical
connections max.
360°.
To ensure safe restarting of the
positioner following interruption
of the power supply, the power
interruption must be longer than
3 seconds.
X1
Electrical connections
Connection Pin Signal name
1 Uv, 24 V DC supply voltage
2 I+, 4...20 mA (set value input)
X1
3 Uv, I-, GND
M12 plug
A coding
4 I+, 4...20 mA (feedback signal)
Uv, Initialization 24 V DC starting
5
the initialization via digital input
5.1
4 5
3
1 2
max. 360°
2
3 5 Connection Pin Signal name
1
4
X1
M12 socket
A coding
37 / 56
Version with external actual
value potentiometer (code
S01)
X4
UP+, output potentiometer supply
1
voltage (+)
UP, input potentiometer wiper
2
X4
voltage
UP-, output potentiometer supply
3
voltage (-)
4 n.c.
5 n.c.
1436 cPos eco
2
1 3
5
4
X4
