12. Naked flames must not be used as a light source for inspecting and checking equipment.
13. Never use caustic solvents, which may damage materials of the pneumatic system
14. After performing installation or other work, ensure that no instruments, rags or spare
parts have been left inside the equipment.
15. Pay particular attention to the safety-relief valves. Thoroughly inspect them and remove
any dust and dirt. They must not be allowed to suffer any loss in function under any circum-
stances. Remember that your safety depends on their functionality!
16. Before beginning work in normal mode after maintenance or repair work, check that the
working pressure, temperature and other characteristics are correctly set. Ensure that all
control devices are installed and functioning properly.
17. When replacing filters, separators etc., wipe away dust, dirt and oil residue from the area
where they are installed with a dry cloth.
18. Protect the motor, air filter, electrical components and control components etc. from com-
ing into contact with condensate. For instance, blow down with dry air.
19. Use protective gloves during installation and repair work in order to avoid burns and injury
(for instance, during oil change).
2.
Technical data and functional description
2.1
Technical data
Article
Model
11100101 A7508
11100102 A7510
11100103 A7513
11100111 A9008
11100112 A9010
11100113 A9013
2.2 General description
The A-Series oil-filled screw compressor series is designed for uninterrupted and efficient-
compressed-air production.
8
Entitlement to free handling of faults arising during the guarantee pe-
riod is forfeited when:
- No warranty service coupon for the compressor or it is filled out
incorrectly
- No records for the compressor's scheduled maintenance are entered
in the compressor's service book
- Unoriginal parts and lubricants are used
Drive power,
Max. operat-
compressor
ing pressure
(kW)
(bar)
8
75
10
13
8
90
10
13
Rated
Output
voltage,
(m 3 /min)
compressor
(phase/V/Hz)
11,8
10,65
9,2
3/380/50
13,8
12,53
10,9
Noise
Screw
(dB)
connection
75
2"
75
Version 1.0
Oil
capacity,
liter
35
