GB
THUNDER iso-fix

INSTALLATION TIPS

1
1) The THUNDER ISO-FIX shall be used with
isofix anchors plus top tether for group I (9-
18kg child).
2) The THUNDER ISO-FIX must be used with
ISOFIX anchors (no top tether needed) at the
same time that with a 3-point seat belt for
group 2, 3 (15-36kg child).
3) The THUNDER ISO-FIX must be fitted as
a forward-facing position in the rear seats of
vehicle.
Four positions of the car seat
The THUNDER can be used in four different
positions. (Fig. 1):
Pull the positioning handle under the front
of the seat forwards or backwards (feel the
spring underneath), then release the handle
on your required position while hearing a dis-
tinct click.
ISO- FIX
Group 1
2 INSTALLATION
Installing method for Group I (9-18 kg)
a) Place the THUNDER ISO-FIX on the vehi-
cle's seat.
b) Rotate the adjuster button in anti-clock
wise direction (F2-A) and pull the isofix an-
chors out-wards as far as it goes, make sure it
can't be pushed back (F2-B).
c) Push the car seat towards the back of ve-
hicle's anchoring point (F3-A) and match the
isofix anchors to the vehicle's anchoring point
until hear a "click" (F3-B).
e) Rotate the adjuster button in anti-clock
wise direction (F4-A) and push the car seat to
the back of vehicle's seat as much as possible
(F4-B).
f) Hook the top tether up and pull as tight as
possible (F7).
ISO- FIX
Groups 2 /3
16
IM-1613.02 THUNDER isofix 30.7.15.indd 16
3 Installing method for Group II (15-25 kg) /
III (22-36 kg)
The installation method is for child within
Group II (15-25 kg) and Group III (22-36 kg).
a) Remove the harness system, including the
belt pads, central buckle and crotch strap.
b) Adjust the headrest by pulling the lifting
handle at your required position according to
your child's height.
c) Place your child into the car seat.
d) Thread the vehicle's shoulder belt from the
Group II belt guide slot (Fig. 14-a), or Group III
belt guide slot (Fig. 14-b), and thread the lap
belt through the belt guide (Fig. 14-c).
So the installation is completed (Fig. 14-d).
e) Joint the belts and buckle up.
Placing your child in the THUNDER car seat
4
Loosen the shoulder belts by pressing the
realease button and pull the shoulder belts
towards you.
Important: Do not pull on the belt pads when
doing so. (Fig. 8-9)
Press the red button to open the buckle. (Fig.
10)
Part the belts over the sides of the shell. (Fig.
11)
Place your child into the shell and make sure
that there are no toys or other hard objects in
the shell. (Fig. 12)
Match buckle tongue sections together and
insert them into the buckle. (Fig. 13)
f) Make sure the shoulder belts fit your child
snugly by pulling the adjuster belt. (Fig. 14)
Note! After you have done the installation,
check it by trying to move it, it shouldn't move
more than an inch side along the belt path,
if it does, tightens the straps or try installing
it again. The belts should never be twisted.
If you are unable to click the tongue sections
into the buckle, unlock the buckle by pressing
the red button and try again.
