To Narrow the Detection Range
The horizontal detection range of Sensor 6800-3x is 180°.
This range can be narrowed to suit local circumstances:
To do this, proceed as follows (see also Fig. 2):
• Cut the masking strip provided to the desired length and/
or width (see marking on the masking strip).
• Affix the marking strip to the area on the front of the lens
of the Sensor 6800-3x where detection is to be pre-
vented.
In this way, the max. range can be reduced in two steps;
you achieve the following values (see also Fig. 3):
1,2 m
2,0 m
2,5 m
Distance in meters
Remote
range
9 m
12 m
15 m
Medium
range
3 m
8 m
11 m
GB
Close-up
range
1 m
3 m
3,5 m
