10. Description of the setup menu

a) "AE" (automatic exposure) submenu

In this menu, you can adjust the exposure depending on the ambient brightness and the ambient conditions at the site
the surveillance camera is installed. Several modes are available to ensure that an optimal picture can be obtained
even when there is backlighting.
"BRIGHTNESS": Adjusts the image brightness
"EXPOSURE MODE": Select exposure mode (the following are available: "GLOBE" = automatic setting, "CENTRE" =
exposure calculated based on the brightness in the centre of the picture, "BLC" = manual setting if there is backlighting,
"FLC" = manual setting if there is upward lighting)
"GAIN": Gain factor for the exposure
"RETURN" = exit submenu and return to the previous menu

b) "WB" (white balance) submenu

Here you can select automatic or manual white balance.
"ATW": Automatic white balance
"MWB": Manual white balance (in "RGAIN" the red component can be adjusted and in "BGAIN" the blue)
"RETURN" = exit submenu and return to the previous menu

c) "DAY-NIGHT" (colour mode) submenu

Usually the surveillance camera automatically switches from a colour display during the day to a black and white image
at night. However this automatic switching can be turned off in this submenu.
"EXT" or "AUTO": Automatic switching based on the ambient light level
"COLOR": Colour display
With this setting, the IR filter stays activated at night; the IR light from the built-in LED cannot be used for
technological reasons.
