outputs:
Display:
Display readout ........................................... -1999...9999 (4 digits)
Decimal point .............................................. Programmable
Digit height .................................................. 13.8 mm
Display updating ......................................... 2.2 times / s
Input outside input range is
indicated by ................................................. Explanatory text
Current outout:
Signal range (span) ...................................... 0...20 mA
Programmable signal ranges ...................... 0...20 / 4...20 /
Load (max.) .................................................. 20 mA / 800 Ω / 16 VDC
Load stability ............................................... ≤ 0.01% of span / 100 Ω
Sensor error detection ................................ 0 / 3.5 / 23 mA / none
NAMUR NE 43 up / downscale .................. 23 mA / 3.5 mA
Output limitation:
on 4...20 and 20...4 mA signals............. 3,8...20.5 mA
on 0...20 and 20...0 mA signals............. 0...20.5 mA
Current limit ................................................. ≤ 28 mA

Relay outputs:

Relay function.............................................. Setpoint
Hysteresis, in % / display counts ............... 0.1...25% / 1...2999
On and Off delay ......................................... 0...3600 s
Sensor error detection ................................ Make / Break / Hold
Max. voltage ................................................ 250 VRMS
Max. current ................................................ 2 A / AC
Max. AC power ........................................... 500 VA
Max. current at 24 VDC............................... 1 A
marine approval:
Det Norske Veritas, Ships & Offshore ......... Standard for Certification No. 2.4
gost R approval:
VNIIM, Cert. no. ........................................... See www.prelectronics.com
observed authority requirements:
EMC 2004/108/EC ...................................... EN 61326-1
LVD 2006/95/EC .......................................... EN 61010-1
UL, Standard for Safety .............................. UL 508
34
20...0 / 20...4 mA
standard:
sensor error detection / sensor error detection outside range:
Sensor error check in 5714 variants
Variant:
Configuration
5714A
Always:
ERR1=NONE, ERR2=NONE:
5714B
else:
O.ERR=NONE:
5714C
else:
ERR1=NONE, ERR2=NONE, O.ERR=NONE:
5714D
else:
Outside range readout (IN.LO, IN.HI):
If the valid range of the A/D converter or the polynomial is exceeded
Input
Range
0..1 V / 0.2..1 V
VOLT
0..10 V / 2..10 V
CURR
0..20 mA / 4..20 mA
POTM
-
TEMP
TC / RTD
Sensor error detection (SE.BR, SE.SH):
Input
Range
CURR
Loop break (4..20mA)
TC
Pt100 2-wire
No SE.SH for Pt10, Pt20 and Pt50
TEMP
Pt100 3-wire
No SE.SH for Pt10, Pt20 and Pt50
Pt100 4-wire
No SE.SH for Pt10, Pt20 and Pt50
Display readout below min. / above max. (-1.9.9.9, 9.9.9.9):
Input
Range
CURR
All
VOLT
All
POTM
-
Sensor error detection:
ON
OFF
ON
OFF
ON
OFF
ON
Readout
Limit
IN.LO
< -25 mV
IN.HI
> 1.2 V
IN.LO
< -25 mV
IN.HI
> 12 V
IN.LO
< -1.05 mA
IN.HI
> 25.05 mA
IN.LO
< -0.5%
IN.HI
> 100.5%
IN.LO
< temperature range
IN.HI
> temperature range
Readout
Limit
SE.BR
<= 3.6 mA; > = 21 mA
SE.BR
> ca. 750 kohm / (1,25V)
SE.BR
> ca. 15 kohm
SE.SH
< ca. 15 ohm
SE.BR
> ca. 15 kohm
SE.SH
< ca. 15 ohm
SE.BR
> ca. 15 kohm
SE.SH
< ca. 15 ohm
Readout
Limit
-1.9.9.9
Display readout <-1999
9.9.9.9
Display readout >9999
-1.9.9.9
Display readout <-1999
9.9.9.9
Display readout >9999
-1.9.9.9
Display readout <-1999
9.9.9.9
Display readout >9999
35
