Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
Use the power tool, accessories and tool bits etc. in ac-
cordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
Service
Have your power tool serviced by a qualified repair per-
son using only identical replacement parts. This will en-
sure that the safety of the power tool is maintained.
Safety Warnings for Multi-function Tools
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting ac-
cessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an
electric shock.
Use the machine only for dry sanding. Penetration of wa-
ter into the machine increases the risk of an electric shock.
Keep hands away from the sawing range. Do not reach
under the workpiece. Contact with the saw blade can lead
to injuries.
Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance. Contact with electric lines can lead to fire
and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.
When working with the machine, always hold it firmly
with both hands and provide for a secure stance. The
power tool is guided more secure with both hands.
Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
Wear protective gloves when changing application
tools/accessories. Application tools/accessories become
hot after prolonged usage.
Do not scrape wetted materials (e. g. wallpaper) or on
moist surfaces. Penetration of water into the machine in-
creases the risk of an electric shock.
Do not treat the surface to be worked with solvent-con-
taining fluids. Materials being warmed up by the scraping
can cause toxic vapours to develop.
Exercise extreme caution when handling the scraper.
The accessory is very sharp; danger of injury.
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Products sold in AUS and NZ only: Use a residual current
device (RCD) with a rated residual current of 30 mA or less.
Bosch Power Tools
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for sawing and cutting wooden mate-
rials, plastic, gypsum, non-ferrous metals and fastening ele-
ments (e. g., unhardened nails, staples). It is also suitable for
working soft wall tiles, as well as for dry sanding and scraping
of small surfaces. It is especially suitable for working close to
edges and for flush cutting. Operate the power tool exclusive-
ly with Bosch accessories.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 On/Off switch
2 Thumbwheel for orbit frequency preselection
3 Vacuum connection
4 Vacuum hose*
5 Handle (insulated gripping surface)
6 Venting slots
7 Tool holder
8 Plunge saw blade
9 Clamping bolt with washer
10 Allen key
11 Sanding plate
12 Sanding sheet
13 Segment saw blade
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Multi-function tool
Article number
Preselection of orbital stroke
rate
Rated power input
Output power
No-load speed n
0
Oscillation angle, left/right
Weight according to
EPTA-Procedure 01/2003
Protection class
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.
English | 11
PMF 180 E
3 603 A00 0..
W 180
W 74
-1
min 15000–21000
° 1.4
kg 1.2
/II
