Connecting the battery

Risk of electrical shock!
always verify the charging device is disconnected from the 230 V aC
outlet when connecting to a battery
▪
always ensure the area around the battery is well ventilated during the charging
process
1 Connect the positive charging clamp (red) to the positive battery terminal
(marked P or +)
2 Connect the negative charging clamp (black) to the body of the vehicle, or in
exceptions to the negative battery terminal (marked n or -)
3 Verify both terminal clamps make good contact with the respective terminals
4 Plug the power plug into a suitable aC mains outlet
In the event of reverse polarity the "Polarity" led will light up red
Charging will not start

Product overview AG 1208, AG 1210, AG 1212

7
6
9
8
1
2
3
4
5
