4 Program
Contact
5
active
Contact
6
manual
7 TRANSFER
8 AC OUT
9 INVERTER
10 Over Temp.
11 Overload
Batt.
12
Low/High
13 OFF
14 EQUALIZE
15–18
POWER
25
MONITOR
4.3

Push buttons

19 ON/OFF
20 RESET
21 Aux. contact
Program mode for
Aux. contact
Auxiliary contact is
activated
Aux. cont.
manually activated
Transfer system is
active. In- coming
voltage is being
sent directly to AC
OUT outlet
There is a voltage
at the AC OUT
outlet
Inverter is working
For the time being
the COMPACT is
out of service
because of
overheating.
The COMPACT is
out of service
because of
overload or short-
circuit
Battery voltage is
too low
COMPACT is
turned off. Turning
it back on is only
possible manually.
Battery equalizing
is set
State of charge of
the battery
Display the value of the output power in % of Pnom (in
inverter mode) and the charge current in Amps (in charger
mode). In this mode the red LED indicates that power
sharing is in use (>100A).
Turning the COMPACT on and off (Help button for
programming)
Alarm signal off (Help button for programming)
Control aux. contact (Help button for programming)
COMPACT V6.9.0
Transfer (bypass) is disabled (see
chap. 4.7)
The inverter is in standby-mode
Forced inverter mode (see chap. 4.5)
Battery voltage is or was to high
COMPACT is for the time being
turned off. Turning it back on will
follow automatically!
LED 15 – Absorption time is running
COMPACT
16/84
