Rear Spacers; Removing The Shelf Holders - AEG S53600CSS0 Benutzerhandbuch

8.4 Rear spacers

4
8.5 Levelling

8.6 Removing the shelf holders

A
C
2
1
3
B
You can find the two spacers in the bag
with documentation.
Do these steps to install the spacers:
1. Release the screw.
2. Engage the spacer below the screw.
3. Turn the spacer to the right position.
4. Tighten again the screws.
When placing the appliance ensure that
it stands level. This can be achieved by
two adjustable feet at the bottom in
front.
Your appliance is equipped with shelf re-
tainers that make it possible to secure
the shelves during transportation.
To remove them proceed as follows:
1. Move the shelf holders in the direc-
tion of the arrow (A).
2. Raise the shelf from the rear and
push it forward until it is freed (B).
3. Remove the retainers (C).
ENGLISH
37
