3
CMS
Property
Display
Digital Audio Interface
Channels
AD/DA Conversion
Sampling Rate
PC Interface
Peak Display
MIDI Interface
Protection
Mixer Outputs (Relay controlled)
Switching Mode Power Supply (µC controlled)
Phantom Power, switchable in groups
Power Requirements (SMPS with auto range mains input)
Safety Class
Ambient Temperature Limits
Dimensions (W x H x D, without lid), mm
Weight, without lid
Net Weight
Shipping Weight
Warranty
Optional Accessories
Lid
Dust Cover for CMS 2200
Rack Mount Kit for CMS 1000
Gooseneck Lamp, 12V/5W, 12", XLR 4 pol.
FS 11 (Footswitch with LED)
Device in rated condition, unity gain (MIC gain 20 dB), all faders position 0 dB, all pots in mid position, master fader +6 dB, unless otherwise
noted.
48
CMS 1000 CMS 1600
128 x 64 pixels, OLED
4 In / 4 Out
44.1 / 48 / 88.2 / 96 kHz
USB2.0, Female Type B
6 dB before Clip
5-pin DIN connector, In / Out
MON 1, MON 2, MASTER A
Mains Over/Undervoltage, High Temperature
100 V to 240 V AC, 50 Hz to 60 Hz
+5 °C to +40 °C (40 °F to 105 °F)
510.5 x 155 x 498.5 663.5 x 155 x 498.5
Rack-mount:
483.0 x 135.0 x 443.7
9.5 kg
(10.5 kg incl. Rack Mount
Kit))
12.5 kg
36 months
F01U169707 F01U169708
(DC-LID1000) (DC-LID1600)
-
F01U169471
(DC-RMK1000CMS)
F01U118983 (DC-LITLITE-4P)
F01U100598 (DC-FS11)
CMS 2200
24-bit
48 V DC
I
818.5 x 155.0 x 498.5
12 kg 14.5 kg
15.0 kg 17.5 kg
-
- F01U169467
(DC-SH2200-3)
- -
