7 Specifications

Property
Order No.
Channels (Mono + Stereo)
Auxiliarys (MON, FX, AUX)
MIC GAIN (Mono)
MIC GAIN (Stereo)
LINE/CD/USB GAIN (Stereo)
THD, at 1 kHz, MBW = 80 kHz
MIC input to Master A L/R outputs, +16 dBu, typical
Frequency Response, -3 dB, ref. 1 kHz
Any input to any Mixer output
Crosstalk, 1 kHz
Fader and FX/AUX/MON-Send attenuation
Channel to Channel
CMRR, MIC input, 1 kHz
Input Sensitivity, all level controls in max. position
MIC
LINE (Mono)
LINE (Stereo)
CD (Stereo)
Maximum Level, mixing desk
MIC inputs
Mono Line inputs
Stereo Line inputs
All other inputs
All other outputs
Input Impedances
MIC
Insert Return
2Track Return & CD In
All other inputs
Output Impedances
Phones
All other outputs
Equivalent Input Noise, MIC input, A-weighted, 150 ohms
Noise, Channel inputs to Master A L/R outputs, A-weighted
Master fader down
Master fader 0 dB, Channel fader down
Master fader 0 dB, Channel fader 0 dB, Channel gain unity
Equalization
LO Shelving
MID Peaking, mono inputs
MID Peaking, stereo inputs
HI Shelving
Master EQ 11-band
(63, 125, 250, 400, 630, 1k, 1.6k, 2.5k, 4k, 6.3k, 12k Hz)
Power Consumption
without lamp
with lamp
Filter
LO-CUT, mono inputs
VOICE FILTER, mono inputs
FEEDBACK FILTER, MON 1/2
Effects
Type
Effects presets
Remote control
CMS 1000 CMS 1600
F01U138112 F01U138114
DC-CMS1000-3-UNIV DC-CMS1600-3-UNIV
6 + 4
2 Pre, 2 Post, 2 Pre/Post switchable
0 to +60 dB
+10 to +60 dB
-10 to +20 dB
< 0.005%
15 Hz to 70 kHz
> 85 dB
< -80 dB
> 80 dB
-74 dBu (155 µV)
-54 dBu (1.55 mV)
-34 dBu (15.5 mV)
-34 dBu (15.5 mV)
+21 dBu
+41 dBu
+30 dBu
+22 dBu
+22 dBu
2 kOhms
> 3.3 kOhms
10 kOhms
> 15 kOhms
47 Ohms
75 Ohms
-130 dBu
-97 dBu
-91 dBu -89 dBu
-83 dBu -82 dBu
±
15 dB / 60 Hz
±
15 dB / 100 Hz to 8 kHz
±
12 dB / 2.4 kHz
±
15 dB / 12 kHz
±
10 dB / Q = 1.5 to 2.5
45 W
50 W
f = 80 Hz, 18 dB/oct.
switchable
70 Hz to 7 kHz, Notch, -9 dB
Dual stereo 24/48-bit multi effects processors
100 Factory + 20 User, Tap-Delay
Footswitch, MIDI
CMS 2200
F01U138115
DC-CMS2200-3-UNIV
12 + 4 18 + 4
-87 dBu
-81 dBu
50 W 55 W
55 W 60 W
